hole in the Mechanism Chassis and that 4 Connectors (P6201,
P6202, P3001, and P4001) are aligned and seated securely.
5. Installation of Cassette Up Ass'y
A. Confirm that the Locking Tab (L-2) under the Cassette Up Ass'y
is in Hole on the Mechanism Chassis when installing the
Cassette Up Ass'y. Then, slide the Cassette Up Ass'y towards
the back.
B. When installing 2 Screws (S-9), slide the Holder Unit (Refer to "
METHOD FOR LOADING/UNLOADING OF MECHANISM" in
SERVICE NOTES) to tighten screws. Then, slide it back to the
EJECT Position.
C. Hook Spring (P-1) to the Drive Rack Arm on the Mechanism
Chassis.
6.2. MECHANISM SECTION
6.2.1. Disassembly/Reassembly Method
