9. The fader is a 60 m m ca rbo n type stereo fade r
which controls the Idt and right channels
si m u I tanec usl y.
o u -,Jut Section
1. 12-point LED bar-graph meters (peak meters)
display all outputs
WR-S208: Three 12'polnt LED bar-graph meters:
11) Sub A/Monitor
12) Sub B/Send
(3) MainlEffect and Solo
WR-S212, WR-S216: Four 12 ::lOlnt LED bar-graph
met ~ rs:
(1) Sub A/E Ifect
(2) Sub B/Send
(3) Monitor
(4) Main and Solo
2. The solo indicator ' _ED shows that the solo level is
Indicated on the 1 2-polnt LED bar-graph meter .
3 . Two effect return cllcuits are provided, each with
L1 -erurn input level control and a pan-pot control.
IMPORTANT NOTICE
1) The mixer OL.:'.puts are available In a f ew seconds
after turning on the power switch. It takes approx-
il~lately 5 minutes for the mixers performance to
be Lily stabilized. C lic k so u nds mig ht be heard
before it is fully warmed up.
21 When using the input selector switch while the
phantom power is tur-ed on, turn tile output fader
down to avoid any popping noise whl::h might
damage the speakers or other equipment con-
nected to the mixer.
CAUTION:
.Jo not connect unbalanced microphones to the
r:iixer wh en using phantom power. Power supply
ilnd "Tl ic rophone may be da M aged.
3) The phantom power supply for mic inputs employs
a slow start system to avoid c::ck sounds f~om be-
Ing produced. Allow 1 minute after pressing phan-
tom power SWltc;-, for voltage to stabilize.
4) When con'lectlng and dlscon'lectlng a rT';crophone
while the p"'antom power is turned on, click sounds
may be heard . Be sure to turn on the phantom
power aLer connecting t-e microphones to the
mixer . When oisco n necting m i crophones, wai t at
least 20 sec . after turning phantom power off .
4. Tile WR-S 212 and WR-S 216 employ 60 mm car-
bon faders for the monitor and send outputs.
5. The WR-S212 and WR-S216 are provided with
stereo output )cks for control room monitOring.
6. Solo level can be adjusted With the solo control
knob, and the solo ndlcator I.ED is located near the
solo control knob to confirm solo monito'ing.
7. The output circui~ contains a built-in sunrning
pea k Indicator LED, which indicates distortion when
m~ltiple inpJ ~ signals are mixed.
5) Fa rinse rtlon at the in put patch points, use a Y-
shaped adaptor cord, wired as tip; return, ring; send
and sleeve ; comll'on on a 114" TRS phone plug.
Ring (Se nd)
TIp (R e um i
T .,5 phOM plug
TS
phone plug
- 2 -
6) All the meters are calibrated to 0 VU = + 4 dBm .
The solo meter indicates actual summing bus level,
which is -10 dBm .
To set signal to nominal level using the solo meter,
adjust trim control for meter reading of -14 dB .
