Panasonic RF-D30BT

13
TQBJ2225
Specifications
Battery Life
(Operate at 80 mW output with “Backlight” set to “10 sec”)

≥ Specifications are subject to change without notice.
≥ Mass and dimensions are approximate.
≥ Total harmonic distortion is measured by a digital spectrum
analyzer.
≥ Battery life may be different depending on the condition of
use.
∫ GENERAL
Power supply
AC adaptor
Input
AC 100 V to 240 V, 50 Hz to 60 Hz, 0.4 A
Output
(For Australia and New Zealand) DC 6.0 V, 2.0 A
(For others) DC 6.0 V, 2.0 A, 12.0 W
Main unit
Power supply input
DC IN terminal DC 6 V, 2 A
Battery DC 6 V (4kR14/LR14)
Power consumption 10 W
Power consumption in standby mode
Approx. 0.3 W
Power source
Manganese
R14 battery
Alkaline LR14
battery
Bluetooth
®
Approx. 4 H Approx. 20 H
FM/DAB Approx. 4 H Approx. 20 H
Dimensions (WkHkD)
261 mmk154 mmk83 mm
Mass
Without batteries Approx. 1.1 kg
With batteries Approx. 1.3 kg
Operating temperature range 0 oC to r40 oC
Operating humidity range
20% to 80% RH (no condensation)
Splash Proof IPX4 or equivalent
∫ AMPLIFIER SECTION
Output power
RMS output power
Front Ch 2 W Mono (4 ≠), 1 kHz, 10% THD
∫ TUNER SECTION
Preset Memory FM 10 stations
Frequency Modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
∫ DAB SECTION
DAB memories 10 channels
Frequency Band (Wavelength)
Band III 5A to 13F
(174.928 MHz to 239.200 MHz)
Sensitivity *BER 4x10
-4
Min Requirement s98 dBm
∫ SPEAKER SECTION
Speaker unit
Full Range 10 cm cone typek1
∫ TERMINAL SECTION
Headphones Stereo, 3.5 mm jack
USB Port
USB Port power (for charging only)
DC OUT 5V1A
∫ Bluetooth
®
SECTION
Version Bluetooth
®
Ver.5.0
Class Class 2
Supported Profiles A2DP, AVRCP
Frequency band 2.4 GHz band FH-SS
Operation Distance 10 m Line of sight
Supported Codec SBC
(For the United Kingdom, Ireland, and
Continental Europe)
Operating Frequency 2402 MHz to 2480 MHz
Maximum Power (EIRP) 4dBm
