Specifications
Battery Life
(Operate at 0.8 W output)

≥ Specifications are subject to change without notice.
≥ Mass and dimensions are approximate.
≥ Total harmonic distortion is measured by a digital spectrum
analyzer.
≥ Battery life may be different depending on the condition of use.
§: MPEG-1 Layer 3, MPEG-2 Layer 3
∫ GENERAL
Power consumption 14 W
Power consumption in standby mode
Approx. 0.2 W
Power supply
AC mains lead AC 220 V to 240 V, 50/60 Hz
Battery DC 12 V (8kR14/LR14)
Manganese R14
battery
Alkaline LR14
battery
CD playback Approx. 4 H Approx. 10 H
FM Approx. 5 H Approx. 13 H
Dimensions (WkHkD)
346 mmk130 mmk239 mm (including protrusions)
Mass
Without batteries Approx. 2.5 kg
With batteries Approx. 3.0 kg
Operating temperature range 0 oC to r40 oC
Operating humidity range
35 % to 80 % RH (no condensation)
∫ AMPLIFIER SECTION
Output power
RMS Output Power (Battery supply)
Front Ch (both ch driven)
6 W per channel (6 ≠), 1 kHz, 10 % THD
Total RMS power 12 W
RMS Output Power (AC power supply)
Front Ch (both ch driven)
10 W per channel (6 ≠), 1 kHz, 10 % THD
Total RMS power 20 W
∫ TUNER SECTION
Preset Memory FM 30 stations
Frequency Modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
∫ DISC SECTION
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3
§
)
Pick up
Wavelength 790 nm (CD)
∫ SPEAKER SECTION
Speaker unit(s)
Full Range 8 cm cone typek2
∫ TERMINAL SECTION
USB Port For update
