2WAY SYSTEM
Outdoor Unit Maintenance Remote Controller
4
4. Monitoring Operations
Display the indoor unit and outdoor unit sensor
temperatures.
<Operating procedure>
À
Press and hold the (CHECK) button and
buttons simultaneously for 4 seconds or longer to
engage temperature monitor mode.
During temperature monitoring,
is illuminates.
(The display and operations are the same as
for monitor mode using the indoor unit remote
controller.)
Á
Press the button and select the indoor unit
to monitor.
Â
Press the temperature setting and
buttons and select the item code of the temperature
to monitor.
The unit No. of the selected indoor unit, and the
temperature data, are displayed.
Ã
To end monitoring, press the (CHECK) button.
The display returns to the normal display.
NOTE
The display does not blink.
1
4
2
3
