Panasonic S-36PY1E5

1
1-446
Outdoor air intake temp(°C D.B.)
Model
Power
Source
Ambient
Return
Air
25°C 30°C 35°C 40°C 46°C
DB WB TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
S-60PU1E5×2
U-125PE1E5
(U-125PE1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
23
16 12.7 10.2 3.73 12.7 10.3 4.01 12.2 10.0 4.27 11.4 9.7 4.44 8.3 8.3 3.63
19 13.6 7.7 3.89 13.6 7.7 4.18 13.1 7.4 4.45 12.2 7.1 4.63 8.9 5.9 3.78
22 14.9 5.0 4.03 14.9 5.0 4.33 14.3 4.8 4.60 13.3 4.5 4.79 9.7 3.3 3.91
25
16 13.2 12.3 3.80 13.2 12.3 4.08 12.7 12.0 4.34 11.8 11.8 4.51 8.6 8.6 3.69
19 14.1 9.7 3.96 14.1 9.7 4.25 13.5 9.3 4.52 12.6 9.0 4.71 9.2 7.7 3.85
22 15.4 7.0 4.10 15.4 6.9 4.40 14.8 6.8 4.68 13.8 6.5 4.87 10.1 5.1 3.98
27
16 13.6 13.6 3.86 13.6 13.6 4.15 13.1 13.1 4.41 12.2 12.2 4.59 8.9 8.9 3.75
19 14.6 11.7 4.03 14.6 11.7 4.32 14.0 11.4 4.60 13.0 11.2 4.78 9.5 9.5 3.91
22 16.0 9.1 4.16 16.0 9.1 4.47 15.3 8.8 4.76 14.3 8.5 4.95 10.4 7.1 4.05
29
16 13.8 13.8 3.87 13.8 13.8 4.16 13.3 13.3 4.42 12.4 12.4 4.60 9.0 9.0 3.76
19 14.8 13.6 4.03 14.8 13.8 4.33 14.2 13.3 4.61 13.2 13.1 4.80 9.7 9.7 3.92
22 16.2 11.0 4.17 16.2 11.1 4.48 15.6 10.7 4.77 14.5 10.5 4.96 10.6 8.9 4.06
32
16 14.0 14.0 3.88 14.0 14.0 4.17 13.5 13.5 4.43 12.6 12.6 4.61 9.2 9.2 3.77
19 15.0 13.8 4.04 15.0 13.9 4.35 14.4 13.5 4.62 13.4 13.3 4.81 9.8 9.8 3.93
22 16.4 11.1 4.18 16.4 11.2 4.50 15.8 10.9 4.78 14.7 10.6 4.97 10.7 8.9 4.07
S-50PU1E5×3
U-140PE1E5
(U-140PE1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
23
16 14.1 11.4 4.87 14.1 11.5 5.23 13.6 11.2 5.56 12.6 10.9 5.79 9.2 9.2 4.73
19 15.1 8.6 5.08 15.1 8.6 5.46 14.5 8.3 5.80 13.5 7.9 6.04 9.8 6.4 4.93
22 16.5 5.6 5.25 16.5 5.6 5.64 15.9 5.4 6.00 14.8 5.0 6.25 10.8 3.7 5.10
25
16 14.6 13.8 4.95 14.6 13.7 5.32 14.0 13.4 5.66 13.1 13.1 5.88 9.5 9.5 4.81
19 15.6 10.7 5.16 15.6 10.8 5.55 15.0 10.4 5.90 13.9 10.1 6.14 10.2 8.6 5.02
22 17.1 7.8 5.34 17.1 7.8 5.74 16.4 7.5 6.11 15.3 7.1 6.35 11.2 5.7 5.19
27
16 15.1 15.1 5.03 15.1 15.1 5.41 14.5 14.5 5.75 13.5 13.5 5.98 9.9 9.9 4.89
19 16.1 13.1 5.25 16.1 13.2 5.64 15.5 12.7 6.00 14.4 12.6 6.24 10.5 10.5 5.10
22 17.7 10.1 5.43 17.7 10.1 5.83 17.0 9.8 6.21 15.8 9.5 6.46 11.5 7.8 5.28
29
16 15.3 15.3 5.05 15.3 15.3 5.42 14.7 14.7 5.77 13.7 13.7 6.00 10.0 10.0 4.90
19 16.4 15.4 5.26 16.4 15.4 5.65 15.7 14.9 6.01 14.6 14.6 6.26 10.7 10.7 5.11
22 17.9 12.3 5.44 17.9 12.4 5.85 17.2 11.9 6.22 16.0 11.7 6.47 11.7 10.0 5.29
32
16 15.5 15.5 5.06 15.5 15.5 5.43 14.9 14.9 5.78 13.9 13.9 6.01 10.2 10.2 4.91
19 16.6 15.6 5.28 16.6 15.5 5.67 16.0 15.2 6.03 14.8 14.8 6.27 10.9 10.9 5.13
22 18.2 12.5 5.46 18.2 12.6 5.86 17.5 12.1 6.24 16.3 11.9 6.49 11.9 10.2 5.30
S-71PU1E5×2
U-140PE1E5
(U-140PE1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
23
16 14.1 11.0 4.87 14.1 11.0 5.23 13.6 10.8 5.56 12.6 10.5 5.79 9.2 9.0 4.73
19 15.1 8.3 5.08 15.1 8.3 5.46 14.5 8.1 5.80 13.5 7.7 6.04 9.8 6.2 4.93
22 16.5 5.6 5.25 16.5 5.6 5.64 15.9 5.4 6.00 14.8 5.0 6.25 10.8 3.7 5.10
25
16 14.6 13.1 4.95 14.6 13.2 5.32 14.0 12.9 5.66 13.1 12.7 5.88 9.5 9.5 4.81
19 15.6 10.4 5.16 15.6 10.4 5.55 15.0 10.1 5.90 13.9 9.7 6.14 10.2 8.2 5.02
22 17.1 7.6 5.34 17.1 7.7 5.74 16.4 7.4 6.11 15.3 7.0 6.35 11.2 5.6 5.19
27
16 15.1 15.1 5.03 15.1 15.1 5.41 14.5 14.5 5.75 13.5 13.5 5.98 9.9 9.9 4.89
19 16.1 12.5 5.25 16.1 12.6 5.64 15.5 12.2 6.00 14.4 12.0 6.24 10.5 10.3 5.10
22 17.7 9.8 5.43 17.7 9.9 5.83 17.0 9.5 6.21 15.8 9.1 6.46 11.5 7.4 5.28
29
16 15.3 15.3 5.05 15.3 15.3 5.42 14.7 14.7 5.77 13.7 13.7 6.00 10.0 10.0 4.90
19 16.4 14.7 5.26 16.4 14.7 5.65 15.7 14.1 6.01 14.6 13.9 6.26 10.7 10.7 5.11
22 17.9 11.8 5.44 17.9 11.9 5.85 17.2 11.5 6.22 16.0 11.2 6.47 11.7 9.5 5.29
32
16 15.5 15.5 5.06 15.5 15.5 5.43 14.9 14.9 5.78 13.9 13.9 6.01 10.2 10.2 4.91
19 16.6 14.9 5.28 16.6 14.8 5.67 16.0 14.4 6.03 14.8 14.1 6.27 10.9 10.9 5.13
22 18.2 12.0 5.46 18.2 12.1 5.86 17.5 11.7 6.24 16.3 11.4 6.49 11.9 9.7 5.30
1-13. Capacity Table
1. Cooling Capacity Performance Data
•
Combination of Multiple Unit
4-Way Cassette Type
TC :Cooling Capacity
SHC :Sensible Heat Capacity
IPT :Cooling Power Consumption
unit : kW
