Pin
No.
Mark I/O Function
64 MO
LOAD
I Test signal input terminal
(“L”:Without loading
mechanism) (Open)
65
SRVTEST
I Test signal input terminal
(“L”:Servo test mode)
(Open)
66 LOAD P I Test signal input terminal
(Open)
67 TEST
KEY IN
I Test signal input terminal
(“L”:Unit key mode) (Open)
68 SRV
LOAD
I Test signal input terminal
(“L”:Using for servo
primary values EEPROM)
69 VCC 3V I Power supply terminal (+
3V)
70 VCC 5V I Power supply terminal (+
5V)
71
SELADDA
I AD/DA converter select
signal input terminal (Open)
72 SLOCK O Spindle lock test signal
output terminal (Not used,
open)
73 TLOCK O Tracking lock signal output
terminal (“H”:lock) (Not
used, open)
74 FLOCK O Focus lock test signal
output terminal (“H”:lock)
(Not used, open)
75 ERROR O Servo error test signal
output terminal (Not used,
open)
76 BUSY O Servo busy test signal
output terminal (Not used,
open)
77
SBPRETRY
O Signal management retry
test signal output terminal
(Not used, open)
78
SRVRETRY
O Servo retry test signal
output terminal (Not used,
open)
79
ARDSKIP
O Address skip test signal
output terminal (Not used,
open)
80 SPMWE O SPM take in test signal
output terminal
