Panasonic SB-PC72 - Page 137

Ref. No. Part No. Part Name & Description Remarks
L8550 G1C100KA0055 CHIP INDUCTOR [M]
L9500 G0ZZ00001930 COIL [M]
L9501 G0B371HA0005 LINE FILTER [M]
L9502 G0AR76Y00001 CHOKE COIL [M]
L9507 G0AR76Y00001 CHOKE COIL [M]
T9500 G4C7AGK00008 MAIN TRANSFORMER [M]
T9501 G4C2AAJ00005 BACK-UP TRANSFORMER [M]
COMPONENT COMBINATIONS
Z971 RGSD12A1445T RADA RESISTOR [M]
Z2602 G2BAD0000003 AM IFT [M]
Z6800 B3RAB0000025 REMOTE SENSOR [M]
Z9500 ERZV10V511CS ZENER [M]
BS6800 RMBX0032 GROUND SPRING [M]
RELAY
RL9500 K6B1AEA00015 POWER RELAY [M]
OSCILLATORS
X2602 H3F1065A0002 DISCRIMINATOR [M]
X2603 H0H720400005 CRYSTAL OSCILLATOR [M]
X6800 H2A1005A0005 10MHZ RESONATOR [M]
X6801 H0A327200115 CRYSTAL OSCILLATOR [M]
X8621 H0J270500085 CRYSTAL OSCILLATOR [M]
DISPLAY TUBES
FL6800 A2BD00000125 FL DISPLAY [M]
FL8101 F1H0J1050022 CHIP CAPACITOR [M]
FL8102 F1H0J1050022 CHIP CAPACITOR [M]
FL8103 F1H0J1050022 CHIP CAPACITOR [M]
FL8104 F1J1E1040022 CHIP CAPACITOR [M]
FUSE
F1 K5D162BLA013 1.6A FUSE 250V [M]
FUSE HOLDERS
FC1 K3GE1BA00021 FUSE CLIP [M]
FC2 K3GE1BA00021 FUSE CLIP [M]
FUSE PROTECTORS
FP5833 K5G401A00008 FUSE PROTECTOR [M]
FP9500 K5G102A00023 FUSE PROTECTOR [M]
FP9501 K5G402A00025 FUSE PROTECTOR [M]
HOLDERS
H5803 K1YF10000006 10P WIRE HOLDER [M]
H5804 K1YF11000004 11P WIRE HOLDER [M]
H5900 K1YF11000004 11P WIRE HOLDER [M]
H5901 K1YF10000006 10P WIRE HOLDER [M]
H6800 RMR0316 7P WIRE HOLDER [M]
H6805 K1YF05000001 5P CABLE HOLDER [M]
H6806 K1YF05000001 5P CABLE HOLDER [M]
H6807 K1YF06000001 6P CONNECTOR [M]
H6810 K1YZ02000015 2P WIRE HOLDER [M]
H9500 K1YF15000004 15P WIRE HOLDER [M]
H9502 REXX0481 3P WIRE HOLDER & 2P FLAT
WIRE (W9502)
[M]
JACKS
JK2601 K4BC03A00008 JK ANETENNA [M]
JK2801 K1CB105B0039 JK S-VIDEO [M]
JK2802 K2HA408B0061 JK COMP/VIDEO [M]
JK2803 K2HA204B0166 JK PIN RCA [M]
Ref. No. Part No. Part Name & Description Remarks
JK2804 K2HA102B0064 JK S.W [M]
JK6800 K2HB102J0038 JK [M]
JK6801 K2HC103A0024 JK SMALL SIGN [M]
JK6802 K2HB102J0038 JK [M]
JK9500 K2AA2B000011 JK AC INLET [M]
JK9501 K4BC04B00084 JK SPEAKER [M]
JK9502 K4BC06B00063 JK 6P SPEAKER [M]
EARTH TERMINAL
E5801 SNE1004-3 EARTH TERMINAL [M]
WIRES
W1 REU13W125XX WIRE [M]
W1002 RWJ0102050CK MOTOR WIRE [M]
CHIP JUMPERS
W2087 ERJ3GEY0R00V CHIP JUMPER [M]
W2090 ERJ3GEY0R00V CHIP JUMPER [M]
W2091 ERJ3GEY0R00V CHIP JUMPER [M]
W2094 ERJ3GEY0R00V CHIP JUMPER [M]
W2095 ERJ3GEY0R00V CHIP JUMPER [M]
W2096 ERJ3GEY0R00V CHIP JUMPER [M]
W2099 ERJ3GEY0R00V CHIP JUMPER [M]
W2101 ERJ3GEY0R00V CHIP JUMPER [M]
W2103 ERJ3GEY0R00V CHIP JUMPER [M]
W2104 ERJ3GEY0R00V CHIP JUMPER [M]
W2125 ERJ3GEY0R00V CHIP JUMPER [M]
W2126 ERJ3GEY0R00V CHIP JUMPER [M]
W2127 ERJ3GEY0R00V CHIP JUMPER [M]
W2128 ERJ3GEY0R00V CHIP JUMPER [M]
W2130 ERJ3GEY0R00V CHIP JUMPER [M]
W2131 ERJ3GEY0R00V CHIP JUMPER [M]
W2132 ERJ3GEY0R00V CHIP JUMPER [M]
W2133 ERJ3GEY0R00V CHIP JUMPER [M]
W2919 ERJ3GEY0R00V CHIP JUMPER [M]
W2999 ERJ3GEY0R00V CHIP JUMPER [M]
W3002 ERJ3GEY0R00V CHIP JUMPER [M]
W3003 ERJ3GEY0R00V CHIP JUMPER [M]
W3004 ERJ3GEY0R00V CHIP JUMPER [M]
W3005 ERJ3GEY0R00V CHIP JUMPER [M]
W3006 ERJ3GEY0R00V CHIP JUMPER [M]
W3007 ERJ3GEY0R00V CHIP JUMPER [M]
W3008 ERJ3GEY0R00V CHIP JUMPER [M]
W3009 ERJ3GEY0R00V CHIP JUMPER [M]
W3011 ERJ3GEY0R00V CHIP JUMPER [M]
W6810 ERJ3GEY0R00V CHIP JUMPER [M]
W6830 ERJ3GEY0R00V CHIP JUMPER [M]
W6882 ERJ3GEY0R00V CHIP JUMPER [M]
W6886 ERJ3GEY0R00V CHIP JUMPER [M]
W6887 ERJ3GEY0R00V CHIP JUMPER [M]
W6888 ERJ3GEY0R00V CHIP JUMPER [M]
W6889 ERJ3GEY0R00V CHIP JUMPER [M]
W6890 ERJ3GEY0R00V CHIP JUMPER [M]
W6891 ERJ3GEY0R00V CHIP JUMPER [M]
W6901 ERJ3GEY0R00V CHIP JUMPER [M]
W6902 ERJ3GEY0R00V CHIP JUMPER [M]
W6906 ERJ3GEY0R00V CHIP JUMPER [M]
W6907 ERJ3GEY0R00V CHIP JUMPER [M]
W6908 ERJ3GEY0R00V CHIP JUMPER [M]
W6915 ERJ3GEY0R00V CHIP JUMPER [M]
W6916 ERJ3GEY0R00V CHIP JUMPER [M]
W6919 ERJ3GEY0R00V CHIP JUMPER [M]
D6814 ERJ3GEY0R00V DIODE [M]
RESISTORS
R1 ERDS2TJ104T 100K 1/4W [M]
R2 ERDS2TJ104T 100K 1/4W [M]
R3 ERDS2TJ221T 220 1/4W [M]
R4 ERDS2TJ104T 100K 1/4W [M]
137
SA-VK725DEE
