Panasonic SC-BTT196

Reference
45
VQT3X51
Specifications
* The impedance of all the speakers is 3 ≠.
* This unit supports “HDAVI Control 5” function.
Specifications are subject to change without notice.
GENERAL
Power consumption: 83 W
Power consumption in
standby mode: Approx. 0.05 W
Power supply: AC 120 V, 60 Hz
Dimensions (WkHkD):
430 mm k 47 mm k 263 mm
(16
15
/16qk1
55
/64qk10
23
/64q)
Mass (Weight): Approx. 2.4 kg (5.3 lbs)
Operating temperature range:
0 o C to 40 o C (32
o
F to 104
o
F )
Operating humidity range: 35 % to 80 % RH
(no condensation)
AMPLIFIER SECTION
RMS TOTAL POWER OUTPUT: 1000 W
1 kHz, 10 % total harmonic distortion
FRONT:
160 W per ch (3 ≠)
CENTER: 160 W per ch (3 ≠)
SURROUND: 160 W per ch (3 ≠)
100 Hz, 10 % total harmonic distortion
SUBWOOFER :
200 W per ch (3 ≠)
FTC TOTAL POWER OUTPUT: 430 W
120 Hz to 20 kHz, 1.0 % total harmonic distortion
FRONT: 60 W per ch (3 ≠)
CENTER: 90 W per ch (3 ≠)
SURROUND: 60 W per ch (3 ≠)
45 Hz to 120 Hz, 1.0 % total harmonic distortion
SUBWOOFER: 100 W (3 ≠)
Audio Input
AUX: k 1
Digital Audio Input
Optical k 1
Sampling frequency:
32 kHz, 44.1 kHz, 48 kHz
Audio Format:
PCM, Dolby Digital, DTS
FM TUNER SECTION
Frequency range: 87.9 MHz to 107.9 MHz (200 kHz step),
87.5 MHz to 108.0 MHz (100 kHz step)
Antenna terminals: 75 ≠ (unbalanced)
SPEAKER SECTION*
FRONT SPEAKERS
[BTT196] [BTT195]
Full range: 6.5 cm (2
1
/2q) CONE TYPE
Dimensions (WkHkD):
292 mm k 1185 mm k 292 mm
(11
1
/2qk46
21
/32qk11
1
/2q)
Mass (Weight): Approx. 2.42 kg (5.3 lbs)
[BT T 190]
Full range: 6.5 cm (2
1
/2q) CONE TYPE
Dimensions (WkHkD):
80 mm k 139 mm k 71 mm
(3
5
/32qk5
1
/2qk2
13
/16q)
Mass (Weight): Approx. 0.37 kg (0.8 lbs)
CENTER SPEAKER
Full range: 6.5 cm (2
1
/2q) CONE TYPE
Super Tweeter: Piezo type
Dimensions (WkHkD): 280 mmk84 mmk78 mm
(11
1
/32qk3
5
/16qk3
3
/32q)
Mass (Weight): Approx. 0.53 kg (1.2 lbs)
SURROUND SPEAKERS
Full range: 6.5 cm (2
1
/2q) CONE TYPE
Dimensions (WkHkD): 80 mmk139 mmk71 mm
(3
5
/32qk5
1
/2qk2
13
/16q)
Mass (Weight): Approx. 0.37 kg (0.8 lbs)
SUBWOOFER
Woofer: 16 cm (6
1
/2q) CONE TYPE
Dimensions (WkHkD):
145 mm k 289.5 mm k 258 mm
(5
23
/32qk11
13
/32qk10
5
/32q)
Mass (Weight): Approx. 3.0 kg (6.6 lbs)
TERMINAL SECTION
USB slot: USB2.0: 2 system
SD card slot: Connector: 1 system
Ethernet: 10BASE-T/100BASE-TX 1 system
VIDEO SECTION
Signal system: NTSC
HDMI AV output*
Output
connector: Type A (19 pin)
LASER Specification
Class I LASER Product
Wave length:
790 nm (CDs)/660 nm (DVDs)/405 nm (BDs)
Laser power: No hazardous radiation is emitted
with the safety protection
