Panasonic SC-GA10 User Manual

TQBJ2056
17
You can check the Wi-Fi signal strength where
the unit is located.
Preparation
≥ Connect this unit to the network. (l 10)
Touch and hold [NET] and [AUX] for at
least 4 seconds.
The status indicators (l 7) will light up and
show the strength.

≥ It is recommended to have a signal strength of 3. Change
the position or angle of your wireless router or this unit if
the indication is 2 or 1, and see if the connection
improves.
≥ If the strength is level 0, the unit cannot establish a link
with the wireless router.
Wi-Fi signal strength
Level 0 (no signal)
Level 1 (weak)
Level 2 (middle)
Level 3 (strong)
SC-GA10-TQBJ2056.book 17 ページ ２０１８年１月２２日 月曜日 午後３時５５分

Panasonic SC-GA10 Specifications

General

Woofer	Yes
Speaker type	2-way
Woofer diameter	80 mm
Number of drivers	3
Number of speakers	1
Audio output channels	2.1 channels
Impedance	8 Ω
RMS rated power	40 W
Total Harmonic Distortion (THD)	10 %
Frequency range	2.4 - 5 GHz
Bluetooth version	4.2
Connectivity technology	Wired & Wireless
Recommended usage	Universal
Virtual assistant	Google Assistant
Audio formats supported	AAC, SBC
Mobile operating systems supported	Android, iOS
Amplifier class	D
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	0.5 W
Power consumption (typical)	11 W
Product type	2.1 portable speaker system
Product color	Black
Product design	Rectangle
Volume control	Touch

Weight and Dimensions

Width	100 mm
Height	284 mm
Weight	1700 g
