10
g AMPLIFIER SECTION
RMS Output Power Stereo Mode
Front Ch (both ch driven) 5 W per channel (6 Ω), 1 kHz, 10 % THD
PMPO output power 95 W
FTC Output Power Stereo Mode
Front Ch (both ch driven) 4.5 W per channel (6 Ω),
60 Hz to 20 kHz, 10 % THD
Total FTC Stereo mode power 9 W
Phone jack
Terminal Stereo, 3.5 mm (1/8") jack
Output level (CD, 1 kHz, -20 dB) max. 0.385 mW + 0.385 mW, 32 Ω
Aux (Rear)
Sensitivity
Normal level 504 mV, 12.4 kΩ
High level 100 mV, 12.4 kΩ
Terminal Stereo, 3.5 mm (1/8") jack
g TUNER SECTION
Preset Memory FM 30 stations
AM 15 stations
Frequency Modulation (FM)
Frequency range 87.9 MHz to 107.9 MHz (200 kHz step)
87.5 MHz to 108.0 MHz (100 kHz step)
Antenna terminals 75 Ω (unbalanced)
Amplitude Modulation (AM)
Frequency range 520 kHz to 1710 kHz (10 kHz step)
g DISC SECTION
Disc played [8 cm (3") or 12 cm (5")]
(1) CD-Audio (CD-DA)
(2) CD-R/RW (CD-DA, MP3)
(3) MP3*
* MPEG-1 Layer 3, MPEG-2 Layer 3
Pick up
Wavelength 785 nm
Laser power CLASS 1
Audio Output (Disc)
Number of channels FL, FR, 2 channel
g SPEAKER SECTION
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s)
Full range 8 cm (3
1
/
8
") Cone type
Impedance 6 Ω
Output sound pressure 83 dB/W (1.0 m)
Frequency range 60 Hz to 25 kHz (-16 dB)
90 Hz to 22 kHz (-10 dB)
g GENERAL
Power supply AC 120 V, 60 Hz
Power consumption 14 W
Dimensions (W x H x D) 384 mm x 214 mm x 112 mm
(15
1
/
8
" x 8
7
/
16
" x 4
13
/
32
")
(D = 69 mm (2
3
/
4
") minimum)
(D = 147 mm (5
25
/
32
") tray open)
Mass (Weight) Approx. 2.1 kg (4.6 lb.)
Operating temperature range 0 °C to +35 °C
(+32 °F to +95 °F)
Operating humidity range 35 % to 80 % RH (no condensation)
Power consumption in standby mode: 0.18 W (approx.)
Specifications are subject to change without notice.
Total harmonic distortion is measured by the digital spectrum
analyzer.
•
•
Specifications
