Panasonic SC-HTB250 User Manual

8
TQBJ2086
Remote control
[HTB258] [HTB250]
[HTB208] [HTB200]
A Switch the main unit on or off
B [HTB258] [HTB250]
Adjust the subwoofer level (~12)
C Dim the indicators on the main unit
D Select the sound mode (~12)
E Select the HDMI (ARC) device as the source
F Select the optical device as the source
G Adjust the volume level (~12)
H Mute the sound (~12)
I Select the Bluetooth
®
device as the source
To start Bluetooth
®
pairing, press and hold
[ -PAIRING ].
█ Preparing the remote control
Before using for the first time
Remove the insulation sheet.
Replacing the battery
Replace with a new battery (CR2025 lithium
battery).
Insert a new battery with the (+) side facing up.
MUTE
DIMMER
SUBWOOFER
SOUND
HDMI (ARC)
OPTICAL
PAIRING
MUTE
DIMMER SOUND
HDMI (ARC)
OPTICAL
PAIRING
Insulation
sheet
TQBJ2086_en.fm Page 8 Wednesday, December 27, 2017 2:30 PM
offset printing

Panasonic SC-HTB250 Specifications

General

Audio decoders	DTS Digital Surround, Dolby Digital
RMS rated power	120 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Number of woofer drivers	1
Full-range driver diameter	100 mm
Soundbar speaker RMS power	80 W
Number of full-range drivers	4
Full-range driver diameter (imperial)	2 \
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Digital audio coaxial in	-
Subwoofer connectivity	Wireless
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	15 W
FM radio	No
Product color	Black
Docking connector type	Not supported
Subwoofer driver diameter (imperial)	5.5 \
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	135 mm
Width	450 mm
Height	51 mm
Soundbar weight	1600 g
Subwoofer depth	307 mm
Subwoofer width	97 mm
Subwoofer height	451 mm
Subwoofer weight	4400 g
