Panasonic SC-HTB400 User Manual

7
TQBJ2216
Remote control
A Switch the main unit on or off
B Select the input source
[HTB400]
[HTB600]
C Select the setup menu (~19)
D Select the sound mode (~18)
E Select the Bluetooth
®
device as the source
(~17)
To start Bluetooth
®
pairing, press and hold
[ -PAIRING].
F Adjust the volume level (~18)
G Mute the sound (~18)
H Select and confirm the option
█ Preparing the remote control
Before using for the first time
Remove the insulation sheet.
Replacing the battery
Replace with a new battery (CR2025 lithium
battery).
Insert a new battery with the (+) side facing up.
MUTE
SETUP
INPUT
SOUND
OK
PAIRING
TV BT
TV BT HDMI
Cautions!
Avoid the use in the following conditions
• High or low extreme temperatures during use,
storage or transportation.
• Replacement of a battery with an incorrect
type.
• Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery,
that can result in an explosion.
• Extremely high temperature and/or extremely
low air pressure that can result in an explosion
or the leakage of flammable liquid or gas.
Insulation
sheet
htb600.400_TQBJ2216_en.fm Page 7 Thursday, May 14, 2020 2:22 PM

Panasonic SC-HTB400 Specifications

General

RMS rated power	160 W
Audio output channels	2.1 channels
Woofer diameter	80 mm
Full-range driver diameter	100 mm
Wi-Fi	No
Bluetooth	Yes
Bluetooth version	4.2
Connectivity technology	Wired & Wireless
Display type	LED
Product color	Black
TV stand usage	-
Number of products included	1 pc(s)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	30 W
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	120 mm
Width	962 mm
Height	56 mm
Cord length	1.5 m
Soundbar weight	3500 g
