Panasonic SC-HTB600 User Manual

12
TQBJ2216
Placing the main unit in a rack or on a table
Additionally required accessories (commercially available)
 Fall prevention cord (x2)
 Screw eyes (to attach the fall prevention cord) (x2)
Note:
• Use commercially available screws that are capable of supporting over 30 kg.
• Use a cord that is capable of supporting over 30 kg (with a diameter of about 1.5 mm).
1 Attach the cord to the main unit.
If the cord cannot be threaded through the holes, try bending the cord, about 5 mm apart from the tip,
at an angle of 45° (as illustrated above).
Attaching the stand to the main unit (Optional)
You can attach the stand (supplied) to the main unit to increase the gap on the bottom of the main unit
so that the you can put it on top of compatible TV stand.
Screw
Screw
Stand
Stand
Cord
Cord
htb600.400_TQBJ2216_en.fm Page 12 Thursday, May 14, 2020 2:22 PM

Panasonic SC-HTB600 Specifications

General

Audio decoders	DTS 96/24, DTS Digital Surround, DTS Virtual:X, DTS-ES, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Surround, Dolby TrueHD
RMS rated power	360 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Product color	Black
TV stand usage	-
Soundbar speaker RMS power	160 W
Subwoofer connectivity	Wireless
Wi-Fi	No
HDMI in	1
Bluetooth version	5.0
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	30 W
Power consumption (standby)	2 W
Subwoofer power consumption	36 W
Cables included	AC
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	120 mm
Width	962 mm
Height	56 mm
Soundbar weight	3300 g
Subwoofer depth	385 mm
Subwoofer width	191 mm
Subwoofer height	413 mm
Subwoofer weight	8400 g
