TQBJ2216
Caution for AC mains lead
(For the AC mains plug of three pins)
For your safety, please read the following text
carefully.
This appliance is supplied with a moulded three
pin mains plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please
ensure that the replacement fuse has a rating of
5-ampere and that it is approved by ASTA or BSI
to BS1362.
Check for the ASTA mark or the BSI mark on
the body of the fuse.
If the plug contains a removable fuse cover you
must ensure that it is refitted when the fuse is
replaced.
If you lose the fuse cover the plug must not be
used until a replacement cover is obtained.
A replacement fuse cover can be purchased from
your local dealer.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type
of AC mains plug (figures A and B). Confirm the
AC mains plug fitted and follow the instructions
below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse
cover.
The symbols on this product (including the
accessories) represent the following:
Sales and Support Information
For the United Kingdom and Ireland
Customer Communications Centre
• For customers within the UK: 0344 844 3899
• For customers within Ireland: 01 289 8333
• Monday – Friday 9:00am – 5:00pm (Excluding
public holidays).
• For further support on your product, please visit
our website: www.panasonic.co.uk
Direct Sales at Panasonic UK
• Order accessory and consumable items for your
product with ease and confidence by phoning
our Customer Communications Centre Monday
– Friday 9:00am – 5:00pm (Excluding public
holidays).
• Or go on line through our Internet Accessory
ordering application at www.pas-europe.com
.
• Most major credit and debit cards accepted.
• All enquiries transactions and distribution
facilities are provided directly by Panasonic UK.
• It couldn’t be simpler!
• Also available through our Internet is direct
shopping for a wide range of finished products.
Take a browse on our website for further details.
Table of contents
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . 2
Caution for AC mains lead . . . . . . . . . . . . . . . . . . 3
Sales and Support Information . . . . . . . . . . . . . . 3
Supplied items . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Overview of controls . . . . . . . . . . . . . . . . . . . . . . 5
Making the connections . . . . . . . . . . . . . . . . . . . . 8
Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Wireless Connections . . . . . . . . . . . . . . . . . . . . 17
Basic control . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Sound menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Firmware updates . . . . . . . . . . . . . . . . . . . . . . . 20
HDMI CEC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 21
Unit care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . 24
References . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure A Figure B
Figure A Figure B
AC
Class II equipment (The construction of the
product is double-insulated.)
ON
Standby
