Panasonic SC-HTB600 User Manual

17
TQBJ2216
Wireless Connections
Active subwoofer wireless connection
[HTB600]
Preparation
Switch on the main unit.
Check that the wireless link is activated.
WIRELESS LINK indicator
On: The wireless link is activated.
Off: The wireless link is not activated.
Blinks: The active subwoofer is trying to activate
the wireless link with the main unit.
Note:
• The wireless link will be activated when the main unit and
the active subwoofer are both switched on.
• The I/D SET button is only used when the main unit is not
paired with the active subwoofer. (~22)
Bluetooth
®
connection
You can connect and play an audio device
wirelessly through Bluetooth
®
.
Preparation
• Switch on the main unit.
• Switch on the Bluetooth
®
feature of the device
and put the device near the system.
• Read the operating instructions of the device for
details.
█ Pairing a device
Preparation
If this system is connected to a Bluetooth
®
device,
disconnect it (~below).
1 Press [ -PAIRING].
If “PAIR” is shown, continue with step 3.
2 Press and hold [ -PAIRING] until “PAIR” is
shown.
3 Select “SC-HTB400” or “SC-HTB600” from
the Bluetooth
®
menu of the device.
The MAC address (e.g., 6C:5A:B5:B3:1D:0F)
may be shown before “SC-HTB400” or
“SC-HTB600”is shown.
If prompted for a passkey, input “0000” or
“1234”.
The name of the connected device is shown for
a few seconds.
Note:
You can pair up to 8 devices with this system. If a 9th device is
paired, the device that has not been used for the longest time
will be replaced.
█ Connecting a paired device
Preparation
If this system is connected to a Bluetooth
®
device,
disconnect it (~below).
1 Press [ -PAIRING].
2 Select “SC-HTB400” or “SC-HTB600” from
the Bluetooth
®
menu of the device.
█ Disconnecting a device
Press and hold [ -PAIRING] until “PAIR” is
shown.
Note:
• This system can only connect to one device at a time.
• When “BT” is selected as the source, this system will
automatically try to connect to the last connected device.
• The Bluetooth
®
device will be disconnected when you select
another source.
htb600.400_TQBJ2216_en.fm Page 17 Thursday, May 14, 2020 2:22 PM

Panasonic SC-HTB600 Specifications

General

Audio decoders	DTS 96/24, DTS Digital Surround, DTS Virtual:X, DTS-ES, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Surround, Dolby TrueHD
RMS rated power	360 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Product color	Black
TV stand usage	-
Soundbar speaker RMS power	160 W
Subwoofer connectivity	Wireless
Wi-Fi	No
HDMI in	1
Bluetooth version	5.0
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	30 W
Power consumption (standby)	2 W
Subwoofer power consumption	36 W
Cables included	AC
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	120 mm
Width	962 mm
Height	56 mm
Soundbar weight	3300 g
Subwoofer depth	385 mm
Subwoofer width	191 mm
Subwoofer height	413 mm
Subwoofer weight	8400 g
