7
TQBJ2216
Remote control
A Switch the main unit on or off
B Select the input source
[HTB400]
[HTB600]
C Select the setup menu (~19)
D Select the sound mode (~18)
E Select the Bluetooth
®
device as the source
(~17)
To start Bluetooth
®
pairing, press and hold
[ -PAIRING].
F Adjust the volume level (~18)
G Mute the sound (~18)
H Select and confirm the option
█ Preparing the remote control
Before using for the first time
Remove the insulation sheet.
Replacing the battery
Replace with a new battery (CR2025 lithium
battery).
Insert a new battery with the (+) side facing up.
MUTE
SETUP
INPUT
SOUND
OK
PAIRING
TV BT
TV BT HDMI
Cautions!
Avoid the use in the following conditions
• High or low extreme temperatures during use,
storage or transportation.
• Replacement of a battery with an incorrect
type.
• Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery,
that can result in an explosion.
• Extremely high temperature and/or extremely
low air pressure that can result in an explosion
or the leakage of flammable liquid or gas.
Insulation
sheet
htb600.400_TQBJ2216_en.fm Page 7 Thursday, May 14, 2020 2:22 PM

Panasonic SC-HTB600 Specifications

General

Audio decoders	DTS 96/24, DTS Digital Surround, DTS Virtual:X, DTS-ES, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Surround, Dolby TrueHD
RMS rated power	360 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Product color	Black
TV stand usage	-
Soundbar speaker RMS power	160 W
Subwoofer connectivity	Wireless
Wi-Fi	No
HDMI in	1
Bluetooth version	5.0
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	30 W
Power consumption (standby)	2 W
Subwoofer power consumption	36 W
Cables included	AC
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	120 mm
Width	962 mm
Height	56 mm
Soundbar weight	3300 g
Subwoofer depth	385 mm
Subwoofer width	191 mm
Subwoofer height	413 mm
Subwoofer weight	8400 g
