VIDEO SECTION
Video system PAL625/50, PAL525/60, NTSC
Composite video output
Output level 1 Vp-p (75
Ω
)
Terminal Pin jack (1 system)
Scart jack (1 system)
S-video output
Y output level 1 Vp-p (75
Ω
)
C output level 0.3 Vp-p (75
Ω
) (PAL)
0.286 Vp-p (75
Ω
) (NTSC)
Terminal S terminal (1 system)
Scart jack (1 system)
Component video output
[NTSC: 480p / 480i, PAL: 576p / 576i]
Y output level 1 Vp-p (75
Ω
)
P
B
output level 0.7 Vp-p (75
Ω
)
P
R
output level 0.7 Vp-p (75
Ω
)
Terminal Pin jack (Y: green, P
B
: blue, P
R
: red)
(1 system)
HDMI AV output
Terminal Type A connector (19-pin)
This unit supports “HDAVI Control 2” function.
g
SPEAKER SECTION
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 3
Ω
1. Woofer 16 cm Cone type
2. Tweeter 2.5 cm Dome type
Input power (IEC) 95 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 7 kHz
Frequency range 50 Hz to 40 kHz (–16 dB)
58 Hz to 32 kHz (–10 dB)
Dimensions (W x H x D) 201 mm x 383 mm x 277 mm
Mass 4.6 k
g
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 3
Ω
1. Woofer 16 cm Cone type
2. Tweeter 2.5 cm Dome type
Input power (IEC) 95 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 7 kHz
Frequency range 50 Hz to 40 kHz (–16 dB)
58 Hz to 32 kHz (–10 dB)
Dimensions (W x H x D) 201 mm x 383 mm x 277 mm
Mass 4.6 k
g
Stack up assembly with front
Dimensions (W x H x D) max
260 mm x 791 mm x 295 mm
Mass 9.6 k
g
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 3
Ω
1. Full range 6.5 cm Cone type
2. Full range 6.5 cm Cone type
Input power (IEC) 95 W (Max)
Output sound pressure 84 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 85 Hz to 25 kHz (–16 dB)
100 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 380 mm x 113 mm x 105 mm
Mass 1.6 k
g
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s) Impedance 3
Ω
1. Woofer 17 cm Cone type
Input power (IEC) 115 W (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 42 Hz to 210 Hz (–16 dB)
46 Hz to 160 Hz (–10 dB)
Dimensions (W x H x D) 231 mm x 385 mm x 236 mm
Mass 5.2 k
g
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance High 3
Ω
1. Woofer 16 cm Cone type
2. Tweeter 2.5 cm Dome type
Input power (IEC) 95 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 7 kHz
Frequency range 50 Hz to 40 kHz (–16 dB)
58 Hz to 32 kHz (–10 dB)
Dimensions (W x H x D) 201 mm x 383 mm x 277 mm
Mass 4.6 k
g
g
GENERAL
Power supply AC 230 to 240V, 50 Hz
Power consumption
165 W
125 W
Dimensions (W x H x D) 205 mm x 385 mm x 342 mm
Mass approx. 7.1 k
g
Operating temperature range + 5°C to + 35°C
(+ 41°F to + 95°F)
Operating humidity range 5% to 90% RH
(no condensation)
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital
spectrum analyzer.
Power consumption in standby mode: approx. 0.9 W
Subwoofer SB-WNC9
