Specifications
AMPLIFIER SECTION
RMS Output Power: Dolby Digital Mode
Front Ch
Surround Ch
Center Ch
Subwoofer Ch
55 W per channel (5 ≠ ), 1 kHz, 10 % THD
55 W per channel (5
≠ ), 1 kHz, 10 % THD
55 W per channel (5
≠ ), 1 kHz, 10 % THD
55 W per channel (5 ≠ ), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power 330 W
FM TUNER, TERMINALS SECTION
Preset Memory FM 30 stations
Frequency Modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50-kHz step)
Antenna terminals 75 ≠ (unbalanced)
Music Port (Front)
Sensitivity
Terminal
100 mV, 6.8 k≠
Stereo, 3.5 mm jack
DISC SECTION
Discs played (8 cm or 12 cm)
(1) DVD (DVD-Video, DivX
§5, 6
)
(2) DVD-R (DVD-Video, DVD-VR, MP3
§2, 5
, JPEG
§4, 5
,
MPEG4
§5, 7
, DivX
§5, 6
)
(3) DVD-R DL (DVD-Video, DVD-VR, DivX
§5, 6
)
(4) DVD-RW (DVD-Video, DVD-VR, MP3
§2, 5
,
JPEG
§4, 5
, MPEG4
§5, 7
, DivX
§5, 6
)
(5) iR/iRW (Video)
(6) iR DL (Video)
(7) CD, CD-R/RW (CD-DA, Video CD, SVCD
§1
,
MP3
§2, 5
, WMA
§3, 5
, JPEG
§4, 5
, MPEG4
§5, 7
, DivX
§5, 6
)
§1 Conforming to IEC62107
§2 MPEG-1 Layer 3, MPEG-2 Layer 3
§3 Windows Media Audio Ver.9.0 L3
Not compatible with Multiple Bit Rate (MBR)
§4 Exif Ver 2.1 JPEG Baseline files
Picture resolution: between 160k120 and
6144k4096 pixels (Sub sampling is 4:0:0, 4:2:0,
4:2:2 or 4:4:4). Extremely long and narrow pictures
may not be displayed.
§5 The total combined maximum number of
recognizable audio, picture and video contents and
groups: 4000 audio, picture and video contents
and 255 groups. (Excluding Root folder)
§6 Plays DivX
®
video.
§7 MPEG4 data recorded with Panasonic SD multi
cameras or DVD video recorders
Conforming to SD VIDEO specifications (ASF
standard)/MPEG4 (Simple Profile) video system/
G.726 audio system
Pick up
Wavelength (DVD/CD) 655/790 nm
Laser power (DVD/CD) CLASS 1M
Audio output (Disc)
Number of channels 5.1 ch (FL, FR, C, SL, SR, SW)
VIDEO SECTION
Video system PAL625/50, PAL525/60, NTSC
Composite video output
Output level
Terminal
1 Vp-p (75 ≠)
SCART jack (1 system)
S-video output
Y output level
C output level
Terminal
1 Vp-p (75 ≠)
PAL; 0.3 Vp-p (75 ≠)
NTSC; 0.286 Vp-p (75 ≠)
SCART jack (1 system)
RGB video output
R output level
G output level
B output level
Terminal
0.7 Vp-p (75 ≠)
0.7 Vp-p (75 ≠)
0.7 Vp-p (75 ≠)
SCART jack (1 system)
HDMI AV output
Terminal 19-pin type A connector
HDAVI Control
This unit supports “HDAVI Control 5” function.
SPEAKER SECTION
[Front\speakers\SB-HF70]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5 ≠
Full range 6.5 cm Cone type
Output sound pressure
Frequency range
Dimensions (WtHtD)
Mass
80 dB/W (1 m)
100 Hz to 25 kHz (j16 dB)
150 Hz to 22 kHz (j10 dB)
80 mmk119 mmk68 mm
0.32 kg
[Surround\speakers\SB-HS70]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5 ≠
Full range 6.5 cm Cone type
Output sound pressure
Frequency range
Dimensions (WtHtD)
Mass
80 dB/W (1 m)
100 Hz to 25 kHz (j16 dB)
150 Hz to 22 kHz (j10 dB)
80 mmk119 mmk68 mm
0.32 kg
[Center\speaker\SB-HC70]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5 ≠
Full range 6.5 cm Cone type
Output sound pressure
Frequency range
Dimensions (WtHtD)
Mass
80 dB/W (1 m)
100 Hz to 25 kHz (j16 dB)
150 Hz to 22 kHz (j10 dB)
80 mmk119 mmk68 mm
0.39 kg
