Connect the AM loop antenna.
Keep the loose antenna cord away from other wires and cords. Do
not screw too tightly. Otherwise, the screwdriver goes around in
circles and cannot be fixed.
Click!
Use a Phillips-head
screwdriver, etc.
Black
Red
White
Connect the AC power supply cord.
To household
AC outlet
To save power when the unit is not to be used for a long time,
unplug it from the household AC power supply cord. You will
need to reset some memory items after plugging in the unit.
Note
Connect the AC power supply cord
after all other connections are
complete.
Portable audio equipment (Cords and equipment not included)
Portable audio player
Plug type:
Ø3.5 mm
(1/8") stereo
➡
Start playback from the
portable audio source.
Note
Adjust the volume and sound quality of this unit and the other equipment. Reduce the level of input signal (for example, by switching off the
equalizer or reducing the volume) of the other equipment before connection. High levels of input signal will distort the sound.
For details, refer to the instruction manual of the other equipment.
•
•
MAIN UNIT
Headphones (not included)
Reduce the volume level and connect the
headphones.
Plug type: Ø3.5 mm (1/8") stereo.
Note
Avoid listening for prolonged periods of
time to prevent hearing damage.
Excessive sound pressure from
earphones and headphones can cause
hearing loss.
•
•
Conserving power
The unit consumes approx. 0.08 W even when it is turned
off with [8, POWER]. To save power when the unit is not
to be used for a long time, unplug it from the household AC
outlet. Remember to reset the radio stations and any other
memory items before using the unit again.
1
2
3
REMOTE
CONTROL
Stand the antenna
up on its base.
AM loop antenna
To Next Page
