Panasonic SC-UA7

18
RQT0B31
Specifications
█ Amplifier section
RMS output power stereo mode
Front Left/Right Ch
375 W per channel (3 Ω), 1 kHz, 30% THD
Subwoofer Ch (x 2)
475 W per channel (2 Ω), 100 Hz, 30% THD
Total RMS stereo mode power 1700 W
█ Tuner, terminals section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.9 MHz to 107.9 MHz (200 kHz step)
87.5 MHz to 108.0 MHz (100 kHz step)
Antenna terminals 75 Ω (unbalanced)
Digital audio input
Optical digital input Optical terminal
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz
AUX IN 1
Audio input Pin jack
AUX IN 2
Audio input Stereo, 3.5 mm (
1
/
8
″) jack
AUDIO OUT
Audio output Pin jack
Microphone
Terminal Mono, 6.3 mm (
1
/
4
″) jack (1 system)
█ USB section
USB port
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
USB device file system FAT12, FAT16, FAT32
█ Bluetooth
®
section
Version Bluetooth
®
Ver. 2.1 + EDR
Class Class 2
Supported profiles A2DP, AVRCP, SPP, OPP
Operating frequency 2.4 GHz band FH-SS
Operation distance 10 m (33 ft) line of sight
█ Speaker section
Front speaker
Speaker unit(s)
Tweeter x 4 6 cm (2
3
/
8
″) cone type
Woofer x 4 8 cm (3
1
/
8
″) cone type
Subwoofer
Speaker unit(s)
Super Woofer x 2 16 cm (6
1
/
2
″) cone type
█ General
Power supply AC 120 V, 60 Hz
Power consumption 190 W
Dimensions (W x H x D) 260 mm x 744 mm x 295 mm
(10
1
/
4
″ x 29
3
/
8
″ x 11
5
/
8
″)
Mass (Weight) 14 kg (30.9 lbs)
Operating temperature range
0°C to +40°C (+32°F to +104°F)
Operating humidity range
20% to 80% RH (no condensation)
Note:
• Specifications are subject to change without notice.
Mass (Weight) and dimensions are approximate.
• Total harmonic distortion is measured by the digital
spectrum analyzer.
Power consumption in standby mode (approximate)
0.4 W
Power consumption in standby mode (approximate)
(With “BLUETOOTH STANDBY” set to “ON”)
0.5 W
