Panasonic TC-P54V10

106
13.2.2. Electrical Replacement Parts List
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
A1 K1KA09A00220 9P CONNECTOR 1
A6 K1KA15A00148 15P CONNECTOR 1
A11 K1KA03AA0190 3P CONNECTOR 1
A12 K1KA02AA0180 2P CONNECTOR 1
A17 K1KA20AA0009 20P CONNECTOR 1
A18 K1KA11AA0715 11P CONNECTOR 1
A25 K1KA13A00152 13P CONNECTOR 1
A30 K1KA12A00317 12P CONNECTOR 1
A31 K1MY68BA0345 68P CONNECTOR 1
A32 K1MY68BA0345 68P CONNECTOR 1
A33 K1MY35BA0345 35P CONNECTOR 1
C10 K1MY55BA0345 55P CONNECTOR 1
C14 K1KA02A00787 2P CONNECTOR 1
C20 K1MY55BA0345 55P CONNECTOR 1
C21 K1MY68BA0345 68P CONNECTOR 1
C22 K1MY68BA0345 68P CONNECTOR 1
C26 K1MY68BA0345 68P CONNECTOR 1
C33 K1KA08B00270 8P CONNECTOR 1
C35 K1KA04BA0107 4P CONNECTOR 1
C36 K1MY68BA0345 68P CONNECTOR 1
C1102 F1J0J106A020 C 0.010UF, K,
16V
1
C1103 F1G1C104A116 C 0.10UF, K, 16V 1
C1104 F1G1C104A116 C 0.10UF, K, 16V 1
C1105 F1G1E103A123 C 0.010UF, K,
25V
1
C1106 F1G1H270A731 C 27UF, 50V 1
C1107 F1G1H180A731 C 18UF, 50V 1
C1108 F1G1C104A116 C 0.10UF, K, 16V 1
C1109 F1H1A1050032 C 10UF, 50V 1
C1111 F1H1A1050032 C 10UF, 50V 1
C1112 F1G1C104A116 C 0.10UF, K, 16V 1
C1114 F1G1C104A116 C 0.10UF, K, 16V 1
C1117 F1G1C104A116 C 0.10UF, K, 16V 1
C1122 F1G1C103A116 C 0.010UF, K,
16V
1
C1123 F1H1A1050032 C 10UF, 50V 1
C1202 F1G1C104A116 C 0.10UF, K, 16V 1
C2023 F1G1C104A116 C 0.10UF, K, 16V 1
C2049 F1G1C104A116 C 0.10UF, K, 16V 1
C2050 F1G1C104A116 C 0.10UF, K, 16V 1
C2055 F1G1H150A731 C 15UF, 50V 1
C2056 F1G1H150A731 C 15UF, 50V 1
C2058 F1G1C104A116 C 0.10UF, K, 16V 1
C2059 F1J1A106A043 C 0.010UF, K,
10V
1
C2060 F1G1C104A116 C 0.10UF, K, 16V 1
C2061 F1G1C104A116 C 0.10UF, K, 16V 1
C2062 F1G1C104A116 C 0.10UF, K, 16V 1
C2063 F1G1C104A116 C 0.10UF, K, 16V 1
C2064 F1H1A1050032 C 10UF, 50V 1
C2102 F1G1C104A116 C 0.10UF, K, 16V 1
C2105 F1G1C104A116 C 0.10UF, K, 16V 1
C2106 F1G1C104A116 C 0.10UF, K, 16V 1
C2107 F1J1A106A043 C 0.010UF, K,
10V
1
C2108 F1J1A106A043 C 0.010UF, K,
10V
1
C2111 F1J1A475A039 C 4.7UF, K, 10V 1
C2118 F1J1A475A039 C 4.7UF, K, 10V 1
C2125 F1G1E103A123 C 0.010UF, K,
25V
1
C2127 F1G1E103A123 C 0.010UF, K,
25V
1
C2128 F1G1C103A116 C 0.010UF, K,
16V
1
C2129 F1G1C103A116 C 0.010UF, K,
16V
1
C2135 F1G1E103A123 C 0.010UF, K,
25V
1
C2136 F1G1E103A123 C 0.010UF, K,
25V
1
C2192 F1J1A106A043 C 0.010UF, K,
10V
1
C2216 F1G1C104A116 C 0.10UF, K, 16V 1
C2244 F1G1C104A116 C 0.10UF, K, 16V 1
C2245 F1G1H102A730 C 1000UF, 50V 1
C2251 F1J1A106A043 C 0.010UF, K,
10V
1
C2263 F1J1A106A043 C 0.010UF, K,
10V
1
C2264 F1J1A106A043 C 0.010UF, K,
10V
1
C2301 F1G1C104A116 C 0.10UF, K, 16V 1
C2302 F1G1C104A116 C 0.10UF, K, 16V 1
C2303 F1J1E105A171 C 1 UF 25V 1
C2305 F1J1E105A171 C 1 UF 25V 1
C2307 F1J1E105A171 C 1 UF 25V 1
C2309 F1J1E105A171 C 1 UF 25V 1
C2313 F1H1A1050032 C 10UF, 50V 1
C2317 F1H1H104A970 C 0.1UF, K, 50V 1
C2319 F1H1H104A970 C 0.1UF, K, 50V 1
C2321 F1H1H104A970 C 0.1UF, K, 50V 1
C2323 F1H1H104A970 C 0.1UF, K, 50V 1
C2333 F1J1E3340003 C 0.33UF, Z, 25V 1
C2335 F1J1E3340003 C 0.33UF, Z, 25V 1
C2337 F1H1H223A970 C 0.22UF, K, 50V 1
C2339 F1H1H223A970 C 0.22UF, K, 50V 1
C2341 F1J1E3340003 C 0.33UF, Z, 25V 1
C2343 F1J1E3340003 C 0.33UF, Z, 25V 1
C2345 F1H1H223A970 C 0.22UF, K, 50V 1
C2347 F1H1H223A970 C 0.22UF, K, 50V 1
C2353 F1H1H104A970 C 0.1UF, K, 50V 1
C2359 F1H1H104A970 C 0.1UF, K, 50V 1
C2375 F1H1H223A970 C 0.22UF, K, 50V 1
C2377 F1H1H223A970 C 0.22UF, K, 50V 1
C2379 F1H1H223A970 C 0.22UF, K, 50V 1
C2381 F1H1H223A970 C 0.22UF, K, 50V 1
C2383 F1G1H102A730 C 1000UF, 50V 1
C2385 F1G1H102A730 C 1000UF, 50V 1
C2387 F1G1H102A730 C 1000UF, 50V 1
C2389 F1G1H102A730 C 1000UF, 50V 1
C2512 ECJ3XB0J106M C 10UF, M,6.3V 1
C2522 F1H1C104A143 C 0.1UF, K, 16V 1
C2523 F1G1H102A730 C 1000UF, 50V 1
C2524 F1G1H102A730 C 1000UF, 50V 1
C3001 F1J1A106A043 C 0.010UF, K,
10V
1
C3006 F1J1A106A043 C 0.010UF, K,
10V
1
C3007 F1J1A106A043 C 0.010UF, K,
10V
1
C3010 F1G1C103A116 C 0.010UF, K,
16V
1
C3013 F1J1A106A043 C 0.010UF, K,
10V
1
C3015 F1J1A106A043 C 0.010UF, K,
10V
1
C3017 F1G1C104A116 C 0.10UF, K, 16V 1
C3019 F1G1C104A116 C 0.10UF, K, 16V 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
