English
7
■ Assembling the pedestal
A
C
D
1
2
B
3
Fall-prevention parts
(p. 8)
●
Accessories may not be placed all together. Take care
not to throw them away unintentionally.
●
For information about the optional accessories, refer
to [eHELP] (Support > Optional accessories).
Assembling / Removing the pedestal
A
Assembly screw (4)
M5 × 15
B
Assembly screw (4)
M4 × 12
C
Bracket (2)
D
Base
50-inch model
55-inch model
65-inch model
To Next Page
