Panasonic TH-86EQ1W - Audio and Remote Control Specs; Speaker Configuration and Audio Output

English
26
Sound
Speakers
86-inch model
75-inch model
15mm×25mm×1/φ70mm×1×2pieces
65-inch model
55-inch model
50-inch model
43-inch model
50 mm × 25 mm × 2 pieces
Audio Output
20 W [10 W + 10 W] (10 % THD)
Remote Control Transmitter
Power source
DC 3 V (battery (AAA/R03/LR03 type) × 2)
Operating range
Approx. 7 m (22.9 ft)
(when operated directly in front of remote control
sensor)
Mass
Approx. 63
/ 2.22 oz (including batteries)
Dimensions (W × H × D)
48 mm × 134 mm × 20 mm / 1.89” × 5.28” × 0.76”
*
1: Environmental temperature to use this unit at high
altitudes (1 400 m (4 593 ft) and higher and below
2 800 m (9 186 ft) above sea level): 0 °C to 35 °C
(32 °F to 95 °F)
*
2: VIERA LINK is not supported.
Note
●
Design and specifications are subject to change
without notice. Mass and dimensions shown are
approximate.
