Model No.
Operating Instructions
Display Operations
Touch Screen LCD Display (for business use)
TH-80LFB70U
TH-80LFB70E
TH-80LFB70W
Please read these instructions before operating your set
and retain them for future reference.
English

Table of Contents

Questions and Answers

  • J
    Joseph WilsonAug 20, 2025
    What to do if my Panasonic Monitor has no picture?
    • C
      cynthiavasquezAug 20, 2025
      If your Panasonic Monitor displays no picture, there might be a few reasons. First, ensure the monitor is plugged into an AC outlet. Then, check if the monitor is switched on by pressing the power switch or the stand-by button on the remote control. Finally, check the Picture and Brightness/Volume settings.
  • D
    daniel39Aug 21, 2025
    Why is there no sound on my Panasonic TH-80LFB70U Monitor?
    • J
      Joan JohnsonAug 22, 2025
      If there is no sound on your Panasonic Monitor, check whether the mute function has been activated on the remote control by adjusting the volume.
  • R
    Robert ThompsonAug 23, 2025
    What to do if the power of my Panasonic TH-80LFB70U automatically turns off?
    • A
      Alexander MaciasAug 23, 2025
      If your Panasonic Monitor unexpectedly turns off, check the settings for “No signal power off”, “PC Power management”, “DVI-D Power management”, HDMI1 Power management, HDMI2 Power management and “No activity power off”. One of these settings may be enabled.
  • K
    Katherine AndersonAug 26, 2025
    What to do if my Panasonic Monitor displays no picture or sound intermittently?
    • D
      Daniel MorrisAug 26, 2025
      If your Panasonic Monitor sometimes shows no picture or sound when using HDMI or DVI signals through a selector or distributor, try turning the power off and on again. If that doesn't work, consider replacing the selector or distributor.
  • B
    brookemeyerAug 27, 2025
    Why are multi-touch operations not working on my Panasonic TH-80LFB70U?
    • A
      Ann RoseAug 27, 2025
      If multi-touch operations are not working on your Panasonic Monitor, it might be because the touch panel, which uses infrared rays, is being affected by light sources. First, check if the “Setup” - “Touch Screen Settings” is set to “On”. Then, move any light sources as far away from the touch panel as possible.
  • L
    Lauren JacobsonAug 30, 2025
    What to do if the RS-232C is uncontrollable on my Panasonic TH-80LFB70U?
    • P
      Paul HenryAug 30, 2025
      If the RS-232C is uncontrollable on your Panasonic Monitor, first check that the connection has been made properly. When controlling the RS-232C command from the RS-232C terminal in the display, make sure that “Control I/F Select” is “RS-232C”, and that “Control I/F Select” is “RS-232C(DIGITAL LlNK)”, and “DIGITAL LINK mode” is “DIGITAL LlNK(RS-232C)” when controlling from the RS-232C terminal of the DIGITAL LINK device.
  • D
    Debra LarsonAug 31, 2025
    What to do if the LAN is uncontrollable on my Panasonic TH-80LFB70U?
    • T
      Troy MartinSep 1, 2025
      If the LAN is uncontrollable on your Panasonic Monitor, check whether the connection has been made properly. Also, verify that “Control I/F Select” is set to “DIGITAL LINK/LAN” when controlling with the WEB browser control or the command control.
  • K
    Keith DavisSep 3, 2025
    What to do if there is no picture or sound from the DIGITAL LINK terminal on my Panasonic TH-80LFB70U?
    • M
      Michelle AyalaSep 3, 2025
      If there is no picture or sound output from the DIGITAL LINK terminal of your Panasonic Monitor, verify that the connection between the video (output) equipment and the twisted pair cable transmitter, and between the twisted pair cable transmitter and the monitor, is properly established.
  • M
    myersbridgetSep 4, 2025
    Why does sending e-mail fail from my Panasonic TH-80LFB70U?
    • S
      Susan CarrilloSep 5, 2025
      If sending e-mail fails from your Panasonic Monitor, verify that the e-mail settings in the Web browser are correct.
  • D
    Devin GoodmanSep 7, 2025
    What does it mean when the power indicator is blinking red on my Panasonic Monitor?
    • K
      Kyle NashSep 7, 2025
      If the power indicator on your Panasonic Monitor is blinking red, there is a possibility of malfunction.

Summary

Important Safety Instructions

Important Safety Notice

WARNING: General Safety

To prevent damage, do not expose to dripping or splashing, or place naked flame sources.

CAUTION: Environment

Appliance intended for environments free of strong electromagnetic fields.

IMPORTANT: THE MOULDED PLUG

Safety and convenience of the moulded three pin mains plug, including fuse replacement.

Safety Precautions

Setup and Installation Precautions

Guidelines for setting up, installing, and transporting the display safely.

Operational Safety and Maintenance

Safe usage, handling problems, cleaning, and maintenance procedures.

Touch Panel Operation Safety

Specific safety instructions for using the touch panel function.

Connections

Audio and Video Input Terminals

Details on connecting speakers, video sources (AV, Component, HDMI, DVI, PC).

Power On; Off

Power Connection and Indicator

Steps for connecting the power cord and understanding the power indicator.

Initial Setup and Power Messages

Initial setup screens and messages displayed upon power on.

Selecting the input signal

Input Selection Method

How to select input signals using the remote control or unit buttons.

Multi-touch Operation

Touch Gestures and Control Menu

Explains touch gestures and how to use the control menu for various functions.

Touch Zoom

Zooming and Scrolling Image

How to enlarge, shrink, and move the image using touch gestures.

Memory Viewer Function

Viewing and Playing Content

How to display and view files, including playback operations and resume.

Using Built-in WhiteBoard

Whiteboard Features and Modes

Overview of whiteboard functions, modes, and input selection.

Drawing Tools and Saving Content

Guide to drawing tools, main menu, saving, and emailing drawings.

Using Miracast(TM)

Miracast Connection Setup

Steps to select Miracast input, start application, and authenticate connection.

On-Screen Menu Displays

Multi-touch Menu Operation

How to operate menus using touch gestures like swipe and tap.

Picture Adjustments

Picture Menu Settings

Basic picture adjustments including mode, backlight, contrast, brightness, color, hue, and sharpness.

Sound Adjustment

Setup menu

Display and Screen Settings

Configuration for touch screen, screensaver, ECO mode, and input labels.

Setup for Input Signals

Troubleshooting

Symptom-Based Diagnostics

Diagnosing common issues like picture, sound, and remote problems.

When using Miracast

Applicable Input Signals

Panasonic TH-80LFB70U Specifications

General IconGeneral
Panel TypeIPS
Viewing Angle (Horizontal/Vertical)178°/178°
Aspect Ratio16:9
Operating SystemNo
Screen Size80 inches
Brightness350 cd/m²
StandardsCE, FCC

Related product manuals
