50
Specifications
Power Source
AC AUTO 110-240 V, 50/60 Hz
(TH-L37X10R only: AC Single 220-240 V, 50/60 Hz)
Power
Consumption
Average use 158 W
Standby condition 0.7 W
Display
panel
Aspect Ratio 16:9
Visible screen size
94 cm (diagonal)
819 mm (W) x 460 mm (H)
Number of pixels 1,049,088 (1,366 (W) x 768 (H))
Sound
Speaker
Full range x 2 pcs, 8
Audio Output 20 W (10 W + 10 W), 10% THD
Headphones M3 (3.5 mm) stereo mini Jack x 1
PC signals
VGA, SVGA, XGA
SXGA
....
(compressed)
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Receiving Systems /
Band name
17 Systems Function 17 Systems Function
1 PAL B, G, H
Reception of broadcast
transmissions and
Playback from Video
Cassette Tape
Recorders
8
NTSC 4.43/5.5 MHz
Playback from Special
VCR’s or DVD
2 PAL I 9
NTSC 4.43/6.0 MHz
3 PAL D, K 10
NTSC 4.43/6.5 MHz
4 SECAM B, G 11
NTSC 3.58/5.5 MHz
5 SECAM D, K 12
NTSC 3.58/6.0 MHz
6 SECAM K1 13
NTSC 3.58/6.5 MHz
7
NTSC M (NTSC
3.58/4.5 MHz)
14 SECAM
I
15
PAL 60 Hz/5.5 MHz
Playback from Special
Disc Players and
Special VCR’s or DVD
16
PAL 60 Hz/6.0 MHz
17
PAL 60 Hz/6.5 MHz
Receiving Channels
(Analogue TV)
VHF BAND
2-12 (PAL/SECAM B, K1)
0-12 (PAL B AUST.)
1-9 (PAL B N.Z.)
1-12 (PAL/SECAM D)
1-12 (NTSC M Japan)
2-13 (NTSC M USA)
UHF BAND
21-69 (PAL G, H, I/SECAM G, K, K1)
28-69 (PAL B AUST.)
13-57 (PAL D, K)
13-62 (NTSC M Japan)
14-69 (NTSC M USA)
CATV
S1-S20 (OSCAR)
1-125 (USA CATV)
C13-C49 (JAPAN)
S21-S41 (HYPER)
Z1-Z37 (CHINA)
5A, 9A (AUST.)
Aerial - Rear VHF / UHF
Operating Conditions
Temperature : 0 °C - 40 °C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1
Input
AUDIO L - R RCA PIN Type x 2 0.5 V[rms]
VIDEO
RCA PIN Type x 1 1.0 V[p-p] (75
)
COMPONENT
Y 1.0 V[p-p] (including synchronization)
P
B
/C
B
, P
R
/C
R
±0.35 V[p-p]
AV2
Input
AUDIO L - R RCA PIN Type x 2 0.5 V[rms]
VIDEO
RCA PIN Type x 1 1.0 V[p-p] (75
)
COMPONENT
Y 1.0 V[p-p] (including synchronization)
P
B
/C
B
, P
R
/C
R
±0.35 V[p-p]
AV3
Input
AUDIO L - R RCA PIN Type x 2 0.5 V[rms]
VIDEO
RCA PIN Type x 1 1.0 V[p-p] (75
)
S VIDEO
Mini DIN 4-pin Y:1.0 V[p-p] (75
) C:0.286 V[p-p] (75
)
Others
HDMI1 / 2 Input
TYPE A Connectors
This TV supports “HDAVI Control 4” function.
PC Input
HIGH-DENSITY D-SUB 15PIN R, G, B/0.7 V[p-p] (75
)
HD, VD/TTL Level 2.0 - 5.0 V[p-p] (high impedance)
Card slot
SD Card slot x 1
Monitor
Output
AUDIO L - R
RCA PIN Type x 2 0.5 V[rms] (high impedance)
VIDEO
RCA PIN Type x 1 1.0 V[p-p] (75
)
Dimensions ( W x H x D )
915 mm x 620 mm x 287 mm (With Pedestal)
915 mm x 577 mm x 97 mm (TV only)
Mass
17.0 k
g
Net (With Pedestal)
14.5 k
g
Net (TV only)
Design and Specifications are subject to change without notice. Weight and Dimensions shown are
approximate.
Note
TH-L37X10KMRSX_EN.indb 50TH-L37X10KMRSX_EN.indb 50 4/29/09 6:13:14 PM4/29/09 6:13:14 PM
