Panasonic TH-P42XT50D - Parts List

Model No. : TH-P42XT50D/G/M/P/S Parts List
Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
PCB N0AE6JK00005 PSS-PRINT COMPLETE 1 PAVCTH
PCB TXNC11RJUU C1-PRINT COMPLETE 1 (RTL)PAVCTH
PCB TXNC21RJUU C2-PRINT COMPLETE 1 (RTL)PAVCTH
PCB TXNSN1RJUU SN-PRINT COMPLETE 1 (RTL)PAVCTH
PCB TXN/K1QTUA K-PRINT COMPLETE 1 (RTL)PAVCTH
PCB TZTNP01PGUD A-PRINT COMPLETE 1 (D) (RTL)PAVCTH
PCB TZTNP01PMUG A-PRINT COMPLETE 1 (G) (RTL)PAVCTH
PCB TZTNP01NMUM A-PRINT COMPLETE 1 (M) (RTL)PAVCTH
PCB TZTNP01PBUP A-PRINT COMPLETE 1 (P) (RTL)PAVCTH
PCB TZTNP01PGUS A-PRINT COMPLETE 1 (S) (RTL)PAVCTH
A1 K1KY07AA0719 7P CONNECTOR 1
A6 K1KY23AA0607 23P CONNECTOR 1
A12 K1KY04AA1094 4P CONNECTOR 1 PAVCTH
A20 K1MY30BA0345 30P CONNECTOR 1
A30 K1MY55BA0345 55P CONNECTOR 1
A50 K1KY05AA0719 5P CONNECTOR 1
C10 K1MY40BA0345 40P CONNECTOR 1
C20 K1MY40BA0345 40P CONNECTOR 1
C21 K1MY55BA0345 55P CONNECTOR 1
C25 K1KY04BA0387 4P CONNECTOR 1 PAVCTH
C0902 F1G1H101A834 C 100PF 50V 1 PAVCTH
C0903 F1G1H101A834 C 100PF 50V 1 PAVCTH
C2000 F1G1E1030005 C 0.01UF 25V 1
C2001 F1J1A106A110 C 10UF, 10V 1 PAVCTH
C2002 F1J1E105A287 C 1UF, 25V 1 PAVCTH
C2003 F1J1E105A287 C 1UF, 25V 1 PAVCTH
C2006 F1G1C104A077 C 0.1UF 16V 1
C2007 F1G1A105A047 C 1UF 10V 1
C2008 F1G1A105A047 C 1UF 10V 1
C2009 F1G1E1030005 C 0.01UF 25V 1
C2010 F1G1A105A047 C 1UF 10V 1
C2013 F1G1E1030005 C 0.01UF 25V 1
C2014 F1G1E1030005 C 0.01UF 25V 1
C2018 F1G1H1020008 C 1000PF 50V 1
C2019 F1G1E1030005 C 0.01UF 25V 1
C2026 F1G1C104A077 C 0.1UF 16V 1
C2032 F1H0J4750004 C 4.7UF, 16V 1
C2810 F1H1H103B047 C 0.01UF, 50V 1 PAVCTH
C2811 F1J1A106A087 C 10UF, 10V 1
C2815 F1H1H103B047 C 0.01UF, 50V 1 PAVCTH
C2821 ECJ1XB1C104K C 0.1UF, Z, 16V 1
C3040 F1J1A106A110 C 10UF, 10V 1 PAVCTH
C3042 F1J1A106A110 C 10UF, 10V 1 PAVCTH
C3045 F1J1A106A110 C 10UF, 10V 1 PAVCTH
C3046 F1G1A105A047 C 1UF 10V 1
C3047 F1G1A105A047 C 1UF 10V 1
C3050 F1K1E106A134 C 10UF, 25V 1
C3057 F1G1A105A047 C 1UF 10V 1
C3058 F1G1A105A047 C 1UF 10V 1
C3084 F1G1A105A047 C 1UF 10V 1
C3085 F1G1A105A047 C 1UF 10V 1
C3086 F1G1A105A047 C 1UF 10V 1
C3105 F1G1H471A834 C 470PF, 50V 1 PAVCTH
C3106 F1G1H471A834 C 470PF, 50V 1 PAVCTH
C3108 F1G1H471A834 C 470PF, 50V 1 PAVCTH
C3109 F1G1H471A834 C 470PF, 50V 1 PAVCTH
C3137 F1G1H471A834 C 470PF, 50V 1 PAVCTH
C3138 F1G1H471A834 C 470PF, 50V 1 PAVCTH
S-29
