Panasonic TX-21JT2P - Replacement Parts List; Important Safety Notice

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Im
p
ortant Safet
y
Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
DEGAUSS COIL 1 028R200015
F.B.T. 2 043221021F
AC POWER CORD 3 0G650809
PANASONIC BADGE 4 7235760001
MAIN P.C.B. 5 A3L917D010K
C.R.T. 6 A51QAE320X47
REMOTE CONTROL 7 EUR511300
SPEAKER 8 SG04D11BNA
CRT P.C.B. 9 TCB411A
AV P.C.B. 10 TEBB07A
TUNER 11 TUWRF4EG-778
BATTERY COVER (REMOTE) 12 UR51EC904A
MISCELLANEOUS COMPONENTS
IR LENS COVER . 711WPAA089
TOP CUSHION . 792UHA0182
BOTTOM CUSHION . 792UHA0183
BATTERY PACK . R6RC/2P
RELAY RY501 ALKS329
I.C.s
MICON/CHROMA IC101 TDA9361
EAROM* IC199 X24C1621JT2P
VERTICAL AMPLIFIER IC401 TDA8357J
5V REGULATOR IC501 KIA7805API
8V REGULATOR IC502 KIA7808API
RGB OUTPUT IC801 TDA6107Q
AUDIO AMPLIFIER IC1001 AN7523
REMOTE RECEIVER OS101 PIC-37142SY
FUSES
FUSE F501 50T040HCC
DIODES
ZENER DIODE D001 MTZJT-773.3B
LED D101 SLR-342VCT32
DIODE D401 AU02A-EIC
DIODE D402 AU02A-EIC
ZENER DIODE D403 MTZJT-773.3B
ZENER DIODE D404 MTZJT-773.3B
ZENER DIODE D406 MTZJT-771.2B
DIODE D407 MA165TA5
ZENER DIODE D408 MTZJT-771.8B
DIODE D409 AU02A-EIC
ZENER DIODE D410 MTZJT-776.8B
DIODE D411 MA165TA5
DIODE D413 AU02A-EIC
DIODE D501 RM11C-EIC
DIODE D502 RM11C-EIC
DIODE D503 RM11C-EIC
DIODE D504 RM11C-EIC
DIODE D505 SB290S
DIODE D506 MTZJT-775.6B
ZENER DIODE D507 MTZJT-771.8B
DIODE D508 SB290S
DIODE D509 MA165TA5
DIODE D510 D28F30DF60
ZENER DIODE D511 MTZJT-771.8B
DIODE D512 1N4937
DIODE D513 SB290S
DIODE D514 MA165TA5
DIODE D515 MA165TA5
DIODE D516 SB290S
DIODE D517 MA165TA5
DIODE D518 MA165TA5
DIODE D519 MA165TA5
ZENER DIODE D520 MTZJT-771.8B
DIODE D521 MA165TA5
ZENER DIODE D522 MTZJT-773.9B
DIODE D524 SB290S
DIODE D525 MA165TA5
DIODE D528 MTZJT-775.6B
DIODE D529 1N4005-EIC
DIODE D530 MA165TA5
DIODE D532 1N4005-EIC
DIODE D533 1N4005-EIC
DIODE D534 1N4005-EIC
DIODE D602 MA165TA5
DIODE D603 MA165TA5
DIODE D801 AU02A-EIC
DIODE D802 AU02A-EIC
DIODE D803 AU02A-EIC
DIODE D804 AU02A-EIC
PHOTO COUPLER IC506 LTV-817M-VB
THERMISTOR(PTC) TH501 B59104-T80-B
TRANSISTORS
TRANSISTOR Q401 TDUF024990
TRANSISTOR Q402 2SA1624
TRANSISTOR Q405 2SC1627Y
POWER TRANSISTOR Q501 KTC3209Y-AT
TRANSISTOR Q502 KTC3203_Y-AT
POWER TRANSISTOR Q503 KTC3209Y-AT
TRANSISTOR Q504 2SC2412
TRANSISTOR Q505 2SC2412
TRANSISTOR Q506 TPAAB05001
POWER TRANSISTOR Q507 KTC3198-ATY
POWER TRANSISTOR Q508 KTC3198-ATY
POWER TRANSISTOR Q509 KTC3209Y-AT
MOSFET Q511 2SK2647-01MR
