Panasonic TX-25MK1P - Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Im
p
ortant Safet
y
Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
MECHANICAL PARTS
C.R.T. 1 A59ECF50X42
SPEAKER 2 EASG12D531P2
TUNER 3 ENG27507GR
REMOTE CONTROL 4 EUR511200
PANASONIC BADGE 5 TBM8E1929
MODEL LABEL 6 TBM8E1952
POWER BUTTON 7 TBX8E070
LID DOOR 8 TKP8E1289
BACK COVER 9 TKU8E00360
CABINET 10 TKY8E184-1
DEGAUSS COIL 11 TLK8E05138
CHASSIS FRAME 12 TMX8E023
E P.C.B. 13 TNP8EE009DG
H P.C.B. 14 TNP8EH002AC
Y P.C.B. 15 TNP8EY012AF
POWER CORD 16 TSX8E0028
FOCUS LEAD ASSY 17 TXFQF8EZ108
BATTERY COVER (REMOTE) 18 UR51EC904A
CRT FIXING SCREW 19 VP17005-32
F.B.T. 20 ZTFL94002A
ANODE LEAD 21 ZTUZAE550A
MISCELLANEOUS COMPONENTS
FIX CLIP 31221212478
84 PIN IC SOCKET PLCC-84-T
PRE-SET LABEL TBM8E1920-1
LID SWITCH TEK6935
LED TUBE TKP8E1179
LED VISOR TKP8E1290
LED HOLDER TMW8E020-1
OUTER CARTON TPC8E4787-1
TOP CUSHION TPD8E608-1
BOTTOM CUSHION TPD8E609
BATTERY PACK UM-3DJ-2P
THERMISTOR R802 232266296706
RELAY RL801 TSE1885-1
C.R.T. SOCKET S351 0330550049
INSTRUCTION BOOKS
BULGARIAN TQB8E2834M
ROMANIAN TQB8E2834N-2
POLISH TQB8E2834P-1
HUNGARIAN TQB8E2834Q-1
CZECH TQB8E2834R-1
ENGLISH TQB8E2834U
I.C.s
AUDIO OUTPUT IC251 LA4282
R.G.B. OUTPUT IC351 TDA6103Q-N3
VERTICAL OUTPUT IC451 LA7845N
VIDEO PROCESSOR IC601 VDP3108BPPC2
E/W CORRECTION IC701 TEA2031A
POWER SUPPLY IC801 STRF6654LF51
ERROR AMPLIFIER IC850 SE140N
12V REGULATORIC851 L78M12MRB
8V REGULATOR IC853 AN78L08TA
LED RECEIVER IC1051 RPM6937-V4
MICRO PROCESSOR IC1101 SDA5450C47
EPROM * IC1102 27C2001-G11
EAROM * IC1103 XDG2-03BP
RESET IC1104 MN1381-R(TA)
RESET IC1105 MN1381-T(TA)
AUDIO PROCESSOR IC2101 MSP3410DPOB4
VIDEO SWITCHING IC3401 TEA2114
FUSES
FUSE F802 19181-3.15
FUSE HOLDERF8021 EYF52BC
FUSE HOLDERF8022 EYF52BC
DIODES
DIODE MA2180TP
DIODE D253 MA700TA5
DIODE D254 MA700TA5
DIODE D354 1SR124-4AT82
DIODE D355 1SR124-4AT82
DIODE D356 1SR124-4AT82
DIODED357 MA165TA5
DIODED358 MA165TA5
DIODED359 MA165TA5
DIODE D360 MTZJT-7715A
DIODED361 MA165TA5
DIODED362 MA165TA5
DIODED363 MA165TA5
DIODED364 MA165TA5
DIODED453 MA165TA5
DIODE D454 ERA15-02V3
DIODE D456 MTZJT-775.6C
DIODED457 MA165TA5
DIODED501 MA165TA5
DIODE D502 1SR124-4AT82
DIODE D511 MA4047
DIODE D551 ERD07-15L7
DIODE D552 RU3LFA1
DIODE D553 1SR124-4AT82
DIODE D554 1SR124-4AT82
DIODED556 MA165TA5
DIODE D557 EU02
DIODE D558 1SR124-4AT82
DIODE D601 DAN217T146
DIODE D603 DAN217T146
DIODE D605 DAN212KT146
DIODED606 MA165TA5
DIODE D607 MA4051
DIODE D609 1SR124-4AT82
DIODE D615 STZ6.2NT146
DIODE D616 STZ6.2NT146
