SERVICE HINTS
How to remove the rear cover
1.
Remove the 9 screws as shown in Fig.2.
LOCATION OF CONTROLS
3
SCREWS
Fig.2.
E-BOARD
Y-BOARD
FOCUS
SCREEN
H-BOARD
Fig.3.
