DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBR2311 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2312 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR3001 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3002 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR3003 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3004 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3005 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3006 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR3007 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3008 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3009 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3010 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3011 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3012 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3013 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3014 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR3015 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3016 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3017 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3018 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR3019 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3020 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3021 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3022 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3023 ERJ6GEYJ123 0.1W 5% 12K
S.M.CARBR3024 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR3025 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3026 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3044 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3046 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3047 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3048 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR3049 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3050 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR3057 ERJ6GEYJ750 0.1W 5% 75
CARBON R3101 ERDS1TJ151 0.5W 5% 150
CARBON R3102 ERDS1TJ151 0.5W 5% 150
METAL R3103 ERG2FJ221 2W 5% 220
METAL R3104 ERG2FJ221 2W 5% 220
S.M.CARBR3105 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3106 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3107 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3108 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3402 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3403 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3404 ERJ6GEYJ242 0.1W 5% 2K4
S.M.CARBR3405 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR3406 ERJ6GEYJ301 0.1W 5% 300
S.M.CARBR3407 ERJ6GEYJ123 0.1W 5% 12K
S.M.CARBR3408 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR3409 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3601 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3602 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3603 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3604 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3605 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3606 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3607 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR3608 ERJ6GEYJ752 0.1W 5% 7K5
S.M.CARBR3609 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR3610 ERJ6GEYJ102 0.1W 5% 1K
CAPACITORS
ELECTC102 ECJ2VF1H103Z 350V
10nF
ELECTC103 ECJ2VF1H104Z 350V
100nF
S.M. CAPC106 ECUV1H560JCX 50V
56pF
ELECTC107 ECJ2VF1H104Z 350V
100nF
ELECT C108 ECA1CM100GB 16V
10µF
S.M. CAPC109 ECUV1H102JCX 50V
1nF
ELECTC110 ECJ2VF1H103Z 350V
10nF
ELECTC111 ECA1HMR33GB 50V
0.33µF
ELECTC117 ECJ2VF1H103Z 350V
10nF
ELECTC118 ECJ2VF1H104Z 350V
100nF
ELECT C119 ECA1CM221GB 16V
220µF
ELECT C120 ECA1CM221GB 16V
220µF
S.M. CAPC121 ECUV1H561KBX 50V
560pF
ELECTC122 ECJ2VB1H102K 350V
1nF
ELECTC123 ECJ2VB1H102K 350V
1nF
S.M. CAPC124 ECUV1H220JCX 50V
22pF
S.M. CAPC125 ECUV1H100DCX 50V
10pF
ELECT C251 ECA1EM100GB 25V
0.1µF
ELECTC252 ECJ2VB1H223K 350V
22nF
ELECT C253 ECA1HM4R7GB 50V
4.7µF
FILM C254 ECQM1H184J 50V
0.18µF
ELECT C255 ECA1EM101GB 25V
100µF
ELECTC256 ECJ2VB1H223K 350V
22nF
ELECT C257 ECA1HM4R7GB 50V
4.7µF
ELECT C258 ECA1EM100GB 25V
0.1µF
FILM C259 ECQM1H184J 50V
0.18µF
ELECT C260 ECA1VM102GB 35V
1nF
ELECT C261 ECA1VM102GB 35V
1nF
FILMC262 ECQM1H474J 50V
470nF
ELECT C263 ECA1HM010GB 50V
1µF
ELECTC264 ECA1HHG222E 50V
2200µF
FILMC265 ECQM1H474J 50V
470nF
ELECT C266 ECA1HM010GB 50V
1µF
ELECTC267 ECJ2YB1H104K 350V
100nF
ELECTC268 ECJ2YB1H104K 350V
100nF
ELECTC270 ECJ2YB1H104K 350V
100nF
ELECTC301 ECJ2VB1C104K 350V
100nF
ELECTC302 ECJ2VB1C104K 350V
100nF
ELECTC303 ECJ2VB1C104K 350V
100nF
ELECT C304 ECA1CM100GB 16V
10µF
FILMC354 ECQM2104KZ 250V
100nF
S.M. CAPC355 ECUV1H222JCX 50V
2.2nF
S.M. CAPC356 ECUV1H222JCX 50V
2.2nF
S.M. CAPC357 ECUV1H222JCX 50V
2.2nF
FILMC358 ECQM1H224J 50V
220nF
CERAMIC C360 ECKC3D152J 2KV
1.5nF
ELECT C361 ECA1HMR47GB 50V
0.47µF
ELECT C363 ECA1VM471GB 35V
470µF
ELECTC364 ECJ2VF1H103Z 350V
10nF
ELECT C366 ECA1CM100GB 16V
10µF
S.M. CAPC451 ECUV1H102JX 50V
1nF
S.M. CAPC453 ECUV1H152KBX 50V
1.5pF
S.M. CAPC454 ECUV1H223KBM 50V
22nF
ELECT C455 ECA1HM100GB 50V
10µF
ELECTC456 ECA1HHG221B 50V
220µF
FILMC458 ECQB1222JF3 100V
2.2nF
FILM C459 222236516154 160V
150nF
CERAMIC C461 ECCR2H270J 500V
27pF
FILMC508 ECQV1H105JZ 50V
1µF
ELECT C509 ECA1VM470B 35V
47µF
ELECTC510 ECJ2YB1H104K 350V
100nF
FILMC511 ECQM2683JZ 250V
68nF
CERAMIC C551 ECKC3D152J 2KV
1.5nF
FILM C552 ECWH15H102JN 1500V
1nF
FILM C554 ECWF2H514J 500V
510nF
FILMC555 ECWH15H103JN 1500V
10nF
FILM C556 ECQM4333JC 400V
33nF
CERAMIC C557 ECKC2H471J 500V
470pF
ELECTC558 ECA1HHG471E 50V
470µF
FILM C559 ECWF2H684J 500V
680nF
