Panasonic TX-25MK1P - Page 19

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M. CAPC2105 ECUV1H102JCX 50V
1nF
S.M. CAPC2106 ECUV1H102JCX 50V
1nF
S.M. CAPC2107 ECUV1H102JCX 50V
1nF
S.M. CAPC2108 ECUV1H102JCX 50V
1nF
S.M. CAPC2109 ECUV1H102JCX 50V
1nF
S.M. CAPC2110 ECUV1H102JCX 50V
1nF
ELECT C2111 ECA1CM100GB 16V
10µF
ELECT C2112 ECA1CM100GB 16V
10µF
ELECT C2113 ECA1HM3R3GB 50V
3.3µF
ELECTC2114 ECJ2VF1H104Z 350V
100nF
S.M. CAPC2115 ECUV1H221JCX 50V
220pF
S.M. CAPC2116 ECUV1H221JCX 50V
220pF
S.M. CAPC2117 ECUV1H221JCX 50V
220pF
S.M. CAPC2118 ECUV1H221JCX 50V
220pF
S.M. CAPC2119 ECUV1H221JCX 50V
220pF
S.M. CAPC2120 ECUV1H221JCX 50V
220pF
ELECT C2121 ECA1CM100GB 16V
10µF
ELECTC2122 ECJ2VF1H104Z 350V
100nF
S.M. CAPC2123 ECUV1H221JCX 50V
220pF
S.M. CAPC2124 ECUV1H070DTX 50V
70pF
S.M. CAPC2125 ECUV1H470JCX 50V
47pF
S.M. CAPC2126 ECUV1H070DTX 50V
70pF
S.M. CAPC2127 ECUV1H010CCX 50V
1pF
S.M. CAPC2128 ECUV1H010CCX 50V
1pF
ELECTC2129 ECA1CM102B 16V
1000µF
ELECT C2130 ECA1CM331B 16V
330µF
ELECTC2131 ECJ2VF1H103Z 350V
10nF
ELECTC2132 ECJ2VF1H103Z 350V
10nF
ELECTC2134 ECJ2VF1H103Z 350V
10nF
ELECT C2135 ECA1HM101GB 50V
100µF
ELECTC2136 ECJ2VF1H104Z 350V
100nF
ELECT C2137 ECA1CM100GB 16V
10µF
S.M. CAPC2138 ECUV1H471KBX 50V
470pF
S.M. CAPC2139 ECUV1H221JCX 50V
220pF
ELECT C2140 ECA1HM101GB 50V
100µF
S.M. CAPC2141 ECUV1H152JCX 50V
1.5pF
S.M. CAPC2301 ECUV1H222JCX 50V
2.2nF
ELECT C2302 ECA1CM470GB 16V
47µF
S.M. CAPC2303 ECUV1H222JCX 50V
2.2nF
ELECT C2304 ECA1CM470GB 16V
47µF
S.M. CAPC3001 ECUV1H222JCX 50V
2.2nF
S.M. CAPC3002 ECUV1H222JCX 50V
2.2nF
ELECT C3003 ECA1CM470GB 16V
47µF
S.M. CAPC3005 ECUV1H561JCX 50V
560pF
ELECTC3006 ECJ3VB1C474K 3.5KV
470nF
S.M. CAPC3007 ECUV1H222JCX 50V
2.2nF
S.M. CAPC3008 ECUV1H222JCX 50V
2.2nF
S.M. CAPC3009 ECUV1H222JCX 50V
2.2nF
ELECT C3010 ECA1CM470GB 16V
47µF
S.M. CAPC3012 ECUV1H561JCX 50V
560pF
ELECTC3013 ECJ3VB1C474K 3.5KV
470nF
S.M. CAPC3014 ECUV1H222JCX 50V
2.2nF
S.M. CAPC3015 ECUV1H222JCX 50V
2.2nF
S.M. CAPC3016 ECUV1H222JCX 50V
2.2nF
ELECT C3017 ECA1CM470GB 16V
47µF
S.M. CAPC3019 ECUV1H561JCX 50V
560pF
ELECTC3020 ECJ3VB1C474K 3.5KV
470nF
S.M. CAPC3021 ECUV1H222JCX 50V
2.2nF
S.M. CAPC3022 ECUV1H222JCX 50V
2.2nF
S.M. CAPC3023 ECUV1H222JCX 50V
2.2nF
ELECT C3024 ECA1CM470GB 16V
47µF
S.M. CAPC3026 ECUV1H561JCX 50V
560pF
ELECTC3027 ECJ3VB1C474K 3.5KV
470nF
S.M. CAPC3028 ECUV1H222JCX 50V
2.2nF
ELECT C3029 ECA1HM101GB 50V
100µF
S.M. CAPC3032 ECUV1H271JCX 50V
270pF
S.M. CAPC3033 ECUV1H271JCX 50V
270pF
S.M. CAPC3034 ECUV1H271JCX 50V
270pF
S.M. CAPC3035 ECUV1H271JCX 50V
270pF
ELECTC3101 ECJ2YB1H104K 350V
100nF
ELECTC3102 ECJ2VB1E104K 350V
100nF
S.M. CAPC3103 ECUV1H561JCX 50V
560pF
S.M. CAPC3104 ECUV1H561JCX 50V
560pF
S.M. CAPC3105 ECUV1H561JCX 50V
560pF
S.M. CAPC3106 ECUV1H561JCX 50V
560pF
ELECT C3107 ECA1HM470GB 50V
47µF
ELECT C3108 ECA1HM470GB 50V
47µF
S.M. CAPC3111 ECUV1H391JCX 50V
390pF
S.M. CAPC3112 ECUV1H271JCX 50V
270pF
FILMC3401 ECQM1H224J 50V
220nF
S.M. CAPC3402 ECUV1H101JCX 50V
100pF
ELECT C3403 ECA1HM101GB 50V
100µF
FILMC3404 ECQM1H224J 50V
220nF
S.M. CAPC3405 ECUV1H180JCX 50V
18pF
S.M. CAPC3406 ECUV1H271JCX 50V
270pF
S.M. CAPC3407 ECUV1H271JCX 50V
270pF
ELECT C3408 ECA1HM101GB 50V
100µF
ELECT C3601 ECA1HM101GB 50V
100µF
ELECTJSE28 ECJ2YB1H104K 350V
100nF
TERMINALS AND LINKS
RCA / HEADPHONE JACK JK2301 JPJ841101320
SCART SOCKET JK3001 0350808500
A.V. TERMINAL JK3101 TJB16673
SWITCHES
SWITCH S801 ESB92S11B
SWITCH S1201 EVQ21405R
SWITCH S1202 EVQ21405R
SWITCH S1203 EVQ21405R
SWITCH S1204 EVQ21405R
SWITCH S1205 EVQ21405R
19
