Panasonic TX-26LE8F - Page 26

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC5075 F1H1C105A008 16V 1000nF
S.M.CAPC5076 F1H1E104A129 25V 100nF
S.M.CAPC5077 F1H1H103A970 50V 10nF
S.M.CAPC5078 F1H1E104A129 25V 100nF
S.M.CAPC5081 F1H1E104A129 25V 100nF
S.M.CAPC5084 F1H1E104A129 25V 100nF
S.M.CAPC5085 F1H1E104A129 25V 100nF
S.M.CAPC5087 F1H1H150A971 50V 15pF
S.M.CAPC5088 F1H1H150A971 50V 15pF
TERMINALS AND LINKS
23P CONNECTOR A1 K1KY23AA0607
30P CONNECTOR A2 K1MN30AA0098
4P CONNECTOR A4 K1KA04AA0192
5P CONNECTOR A5 K1KA05AA0192
A5-SP WIRE A5-SP TXAJTA5NEB
15P CONNECTOR A7 K1KA15AA0194
G51-A7 WIRE A7-G51 TXJ/A7NEB
6P CONNECTOR A8 K1KA06AA0192
A8-V1 WIRE A8-V1 TXJ/A8NEB
2P CONNECTOR A10 K1KA02A00787
8P CONNECTOR A11 K1KA08AA0714
6P CONNECTOR A13 K1KA06AA0104
A13/P3-CN1 INVERTER WICN-A,P TXJ/A13NEB
15P CONNECTOR G51 K1KA15AA0194
SCART SOCKET JK3000 K1FY121A0004
SCART SOCKET JK3050 K1FY121A0004
YUV TERMINAL_ AUD I/OJK3100 K2HA7YYA0001
AV3 TERMINAL JK3700 K4AK30B00001
HDMI TERMINAL JK5000 K1FY119D0002
HDMI TERMINAL JK5001 K1FY119D0002
4P CONNECTOR K1 K1KA04BA0061
A4-K1 WIRE K1-A4 TXJ/K80MDQ-1
A2-PANEL WIRE_LVDSLVDS TXJTA2NEB
8P CONNECTOR V1 K1KA08B00270
SWITCHES
SWITCH SW2501 K0F162B00002
DIFFERENCES FOR MODEL TX--26LE8F
EXPLODED VIEW
A P.C.B. 20 A-26LE8F
AC CORD ASSY 21 TXASX01NXA-2
CABINET ASSY 22 TTY0E0269
MODEL LABEL 23 TBM0E1227
PEDESTAL ASSY 24 TTX0E0004
POWER BUTTON 25 TBX0E84400
MISCELLANEOUS COMPONENTS
IR/LED PANEL . TKP0E91401
INSTRUCTION BOOKS
GERMAN . TQB0E0694A-1
DUTCH . TQB0E0694B-1
ITALIAN . TQB0E0694C-1
FRENCH . TQB0E0694D-1
SPANISH . TQB0E0694E-1
SWEDISH . TQB0E0694F-1
NORWEGIAN . TQB0E0694G-1
FINNISH . TQB0E0694H-1
LITHUANIAN . TQB0E0694I-1
PORTUGUESE . TQB0E0694J-1
DANISH . TQB0E0694K-1
BULGARIAN . TQB0E0694M-1
ROMANIAN . TQB0E0694N-1
LATVIAN . TQB0E0694O-1
POLISH . TQB0E0694P-1
HUNGARIAN . TQB0E0694Q-1
CZECH . TQB0E0694R-1
GREEK . TQB0E0694S-1
TURKISH . TQB0E0694T-1
ENGLISH . TQB0E0694U-1
CROATIAN . TQB0E0694V-1
SLOVAKIAN . TQB0E0694W-1
CD ROM . TQB0E0694X1
ESTONIAN . TQB0E0694Z-1
I.C.s
EEPROM IC1120 X24C26LE8F
DIFFERENCES FOR MODEL TX--26LE8FS
EXPLODED VIEW
A P.C.B. 20 A-26LE8F
AC CORD ASSY 21 TXASX01NXA-2
CABINET ASSY 22 TTY0E0371
MODEL LABEL 23 TBM0E1423
PEDESTAL ASSY 24 TTX0E0009
POWER BUTTON 25 TBX0E85500
MISCELLANEOUS COMPONENTS
IR/LED PANEL . TKP0E92701
INSTRUCTION BOOKS
GERMAN . TQB0E0694A-1
DUTCH . TQB0E0694B-1
ITALIAN . TQB0E0694C-1
FRENCH . TQB0E0694D-1
SPANISH . TQB0E0694E-1
SWEDISH . TQB0E0694F-1
NORWEGIAN . TQB0E0694G-1
FINNISH . TQB0E0694H-1
LITHUANIAN . TQB0E0694I-1
PORTUGUESE . TQB0E0694J-1
DANISH . TQB0E0694K-1
BULGARIAN . TQB0E0694M-1
ROMANIAN . TQB0E0694N-1
LATVIAN . TQB0E0694O-1
POLISH . TQB0E0694P-1
HUNGARIAN . TQB0E0694Q-1
CZECH . TQB0E0694R-1
GREEK . TQB0E0694S-1
TURKISH . TQB0E0694T-1
ENGLISH . TQB0E0694U-1
CROATIAN . TQB0E0694V-1
SLOVAKIAN . TQB0E0694W-1
CD ROM . TQB0E0694X1
ESTONIAN . TQB0E0694Z-1
I.C.s
EEPROM IC1120 X24C26LE8F
DIFFERENCES FOR MODEL TX--26LE8L
EXPLODED VIEW
A P.C.B. 20 A-26LE8L
AC CORD ASSY 21 TXASX01NJA-2
CABINET ASSY 22 TTY0E0269
MODEL LABEL 23 TBM0E1229
PEDESTAL ASSY 24 TTX0E0004
POWER BUTTON 25 TBX0E84400
MISCELLANEOUS COMPONENTS
IR/LED PANEL . TKP0E91401
INSTRUCTION BOOKS
ENGLISH . TQB0E0696
I.C.s
EEPROM IC1120 X24C26LE8L
26
