Panasonic TX-28PB50D - Page 15

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
DUAL VCA (AMPLIFIER) IC2528 M5222FP-E2
DUAL VCA (AMPLIFIER) IC2529 M5222FP-E2
REGULATOR IC2705 PQ1CG21H2RZ
REGULATOR IC2706 PQ1CG21H2RZ
8V REGULATOR IC2707 AN7808LB
POWER SUPPLY IC2708 SI-8090K
REGULATOR IC2709 PQ1CG21H2RZ
SWITCHING IC3001 CXA2069Q-TL
12V REGULATOR IC3002 TDA8601T/C1
VIDEO AMPLIFIER IC3003 CXA1211M-T4
12V REGULATOR IC3302 L78M12MRB
OPERATIONAL AMPLIFIER IC4801 AN6564NS-E1
GEOMAGNETIC CORRECTIONIC4802 PUB4301
LED RECEIVER RM1001 RPM6937
FUSES
FUSE HOLDER F801-1 EYF52BC
FUSE HOLDER F801-2 EYF52BC
FUSE F801 XBA2C50TH15
DIODES
DIODE D001 MA4020
DIODE D002 MA4020
DIODE D003 MA3150HTX
DIODE D004 MA3150HTX
DIODE D010 MA152KTX
DIODE D051 MA4020
DIODE D052 MA4020
DIODE D053 MA152KTX
DIODE D351 ERA15-04V3
DIODE D352 ERA15-04V3
DIODE D353 MA3110LTX
DIODE D355 ERA15-04V3
DIODE D356 ERA15-04V3
DIODE D358 MA151ATX
DIODE D360 ERA15-02V3
DIODE D361 MA151ATX
DIODE D362 MA151ATX
DIODE D363 MA151ATX
DIODE D364 MA3130MTX
DIODE D365 MA3130MTX
DIODE D366 MA3130MTX
DIODE D367 MA3051HTX
DIODE D368 MA3051HTX
DIODE D369 MA3051HTX
DIODE D383 ERA15-04V3
DIODE D385 ERA22-04V3
DIODE D386 ERA15-04V3
DIODE D389 ERA15-04V3
DIODE D452 MA152KTX
DIODE D453 EU02AV1
DIODE D454 MA152KTX
DIODE D455 MA152KTX
DIODE D456 ERA22-02V3
DIODE D465 MA3039HTX
DIODE D502 MA4150TA
DIODE D503 ERA81004V3
DIODE D504 D1NL40V70
DIODE D553 MA167TA5
DIODE D554 EU02
DIODE D555 RH3GLF102
DIODE D557 MA1033MTA
DIODE D558 AU02V0
DIODE D559 FMV-3GULF730
DIODE D560 MA165TA5
DIODE D562 MA182TA
DIODE D570 RU3ANV1
DIODE D580 MA4360
DIODE D591 MA165TA5
DIODE D592 MA4104
DIODE D593 ERA15-02V3
DIODE D594 MA165TA5
DIODE D595 MA4360MTA
DIODE D701 D1NL40V70
DIODE D802 D6SB80LF-B
DIODE D805 MA2240-BLFS
DIODE D809 MA2082-ALFS
DIODE D811 MA2082-ALFS
DIODE D819 ERA22-04V3
DIODE D820 ERA22-04V3
DIODE D821 ERA22-04V3
DIODE D823 PC123FY2
THERMISTOR D825 232266296706
THERMISTOR D826 232266296706
DIODE D843 ERC0510V1
DIODE D844 TVSSR2KL
DIODE D845 RY24V1
DIODE D847 ERA22-10
DIODE D848 PC123FY2
DIODE D851 FMGG26S
DIODE D852 MA4030LTA
DIODE D853 RU2AMLFA1
DIODE D854 RU2AMLFA1
DIODE D855 FMGG2CS
DIODE D856 EU02
DIODE D857 FMGG26S
DIODE D858 MA165TA5
DIODE D859 MA165TA5
DIODE D861 MA165TA5
DIODE D862 MA4360MTA
DIODE D865 MA165TA5
DIODE D867 MA165TA5
DIODE D869 MA165TA5
DIODE D881 MA165TA5
DIODE D885 MA4056HTA
DIODE D886 MA165TA5
DIODE D887 MA165TA5
DIODE D888 EU02
DIODE D891 ERC0510V1
DIODE D953 R2KNLFA1
DIODE D961 MA152KTX
LED D1011 LNH201RFCF6
DIODE D1012 MTZJT-775.1C
DIODE D1152 MA152KTX
DIODE D1153 MA152KTX
DIODE D1302 MA152KTX
DIODE D1305 MA704ATX
DIODE D1306 MA3062MTX
DIODE D1307 MA3091MTX
DIODE D1308 MA152KTX
DIODE D1309 MA152KTX
DIODE D1310 MA3062MTX
DIODE D1311 MA3062MTX
DIODE D1312 MA3062MTX
DIODE D1313 MA3043MTX
DIODE D1315 MA3043MTX
DIODE D2040 MA152KTX
DIODE D2041 MA152KTX
DIODE D2048 MA152KTX
DIODE D2301 TVSRM26V1
DIODE D2302 MTZJT-775.6B
DIODE D2305 MA3047MTX
DIODE D2306 MA29TA5
DIODE D2311 MA1180HTA
15
