Panasonic TX-28PB50D - Waveform Pattern Table

WAVEFORM PATTERN TABLE
Note: All waveforms have been taken using a standard colour bar pattern.
6
32µS
0.8V
R - Y
IC1315 Pin 38
B - Y
IC1315 Pin 39
32µS
0.8V
Video Out
IC3001 Pin 56
2.2V
64µS
R - Out
IC1315 Pin 23
32µS
4V
G - Out
IC1315 Pin 21
4V
32µS
B - Out
IC1315 Pin 19
4V
32µS
VFLB
IC451 Pin 6
1V
20mS
32µS
4V
H - Drive
A3 Pin 10
Vert Drive
A44 Pin 24
10mS
0.9V
HFLB
A3 Pin 11
32µS
4V
Vert Out
IC451 Pin 3
10mS
88V
SVM Out
A44 Pin 43
1V
32µS
E/W Out
IC501 Pin 1
32µS
8V
Luminance In
IC1315 Pin 37
0.9V
32µS
