Panasonic TX-28PB50D - Page 35

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
RELAYS
RELAY RL801 K6B1ADA00010
RELAY RL802 K6B2ADA00004
DIFFERENCES FOR MODEL TX--28PB50D
EXPLODED VIEW
A P.C.B. 19 TNPH0348BL
ANODE CABLE 20 ZTBZAD550A
BACK COVER 21 TKU8E00680
C.R.T. 22 W66EKT10X71
CABINET 23 TKY8E560-1
CONTROL BRACKET 24 TMW8E045
D P.C.B. 25 TNPH0349AM
DEGAUSS COIL 26 TLK8E05175
FBT 28 ZTFM77020A
FOCUS LEAD ASSEMBLY 29 TXJF0C0CJFG
G P.C.B. 30 TNP8EG004AA
L P.C.B. 31 TNPA1726AC
MODEL LABEL 32 TQF8E3198-1
PANASONIC BADGE 33 TBMA060
MISCELLANEOUS COMPONENTS
SET FOOT (FRONT) . TBLG3019
SET FOOT (REAR) . TBLG3020
PRESET LABELRIGHT. TBM8E2138
LID SWITCH . TEK6935
CRT EARTH SPRING . TES2298
SPEAKER PANELEFT . TKP8E1371
SPEAKER PANELRIGHT. TKP8E1376
BOTTOM PANEL LEFT. TKP8E1380
BOTTOM PANEL RIGHT. TKP8E1391-1
ROTATION COIL . TLK8E05177
CARTON . TPC8E4906
TOP CUSHON . TPD8E757
BOTTOM CUSHION . TPD8E758
INSTRUCTION BOOKS
GERMAN TQB8E3299A
ITALIAN TQB8E3299C
FRENCH TQB8E3299D
I.C.s
VERTICAL OUTPUT IC451 LA7845N
EAROM * IC1104 X24BR200-3MD
2.5V REGULATOR IC1252 PQ30RV21B
VIDEO PROCESSOR IC1304 C1AB00001230
2.5V REGULATOR IC2402 PQ30RV21B
COILS
COIL L558 EXCELDR35C
COIL L574 ELHKLB070B
COIL L576 ELC18B221F
COIL L579 ELHKLB061B
CHOKE COIL L702 ELC18B121G
COIL L2005 EXCELDR35V
RESISTORS
S.M.CARBJSA81 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSZ7 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR353 ERJ6ENF1331 0.1W 1% 330
S.M.CARBR363 ERJ6ENF1331 0.1W 1% 330
S.M.CARBR372 ERJ6ENF1331 0.1W 1% 330
CARBONR451 ERDS1TJ3R3 0.5W 5% 3R3
CARBONR452 ERDS1TJ3R3 0.5W 5% 3R3
METALR509 ERX3FJ6R8H 3W 5% 6.8
CARBONR555 ERD25TJ473 0.25W 5% 47K
WOUNDR556 ERF2AKR22 0.5W 5% R22
CARBONR558 ERDS2TJ333T 2W 5% 33K
CARBON R559 ERD25TJ273 0.25W 5% 27K
CARBON R560 ERD25TJ393 0.25W 5% 39K
CARBONR572 ERD25TJ153 0.25W 5% 15K
CARBONR581 ERD25TJ623 0,25W 5% 62K
CARBONR582 ERD25TJ274 0.25W 5% 270K
CARBONR583 ERDS2TJ562 2W 5% 5.6K
FUSIBLER586 ERQ12HJ2R7 0.5W 5% 2.7
METALR591 EROS2TKF8871 2W 1% 8.87K
S.M.CARBR965 ERJ6GEYJ683 0.1W 5% 68K
S.M.CARBR967 ERJ6GEYJ683 0.1W 5% 68K
S.M.CARBR1458 ERJ6ENF6801 0.1W 1% 6K8
S.M.CARBR2481 ERJ6GEYJ473 0.1W 5% 47K
CAPACITORS
CERAMIC C554 ECKC3D681J 2KV 680pF
FILMC558 ECWH20472JVB 200V 4.7nF
FILMC559 ECQF4123JZH 400V 12nF
FILMC561 ECWH20472JVB 200V 4.7nF
FILM C562 ECQF4273JZH 400V 27nF
CERAMIC C573 ECKC2H103J 500V 10nF
FILMC578 ECWF4684JBB 400V 680nF
FILMC579 ECWF4304JBP 400V 300nF
FILMC580 ECWF4304JBP 400V 300nF
FILMC586 ECQB1H473K 50V 47nF
CERAMICC1500 EEVHB1C101P 16V 100pF
FILMC1520 ECQV1H104J 50V 100nF
TERMINALS AND LINKS
CRT SOCKET JK351 0330550049
DIFFERENCES FOR MODEL TX--28PB50F
EXPLODED VIEW
A P.C.B. 19 TNPH0348BN
ANODE CABLE 20 ZTBZAD550A
BACK COVER 21 TKU8E00680
C.R.T. 22 W66EKT10X71
CABINET 23 TKY8E560-1
CONTROL BRACKET 24 TMW8E045
D P.C.B. 25 TNPH0349AM
DEGAUSS COIL 26 TLK8E05175
FBT 28 ZTFM77020A
FOCUS LEAD ASSEMBLY 29 TXJF0C0CJFG
G P.C.B. 30 TNP8EG004AA
L P.C.B. 31 TNPA1726AC
MODEL LABEL 32 TQF8E3212-1
PANASONIC BADGE 33 TBMA060
MISCELLANEOUS COMPONENTS
SET FOOT (FRONT) . TBLG3019
SET FOOT (REAR) . TBLG3020
PRESET LABELRIGHT. TBM8E2138
LID SWITCH . TEK6935
CRT EARTH SPRING . TES2298
SPEAKER PANELEFT . TKP8E1371
SPEAKER PANELRIGHT. TKP8E1376
BOTTOM PANEL LEFT. TKP8E1380
BOTTOM PANEL RIGHT. TKP8E1391-1
CARTON . TPC8E4906
TOP CUSHON . TPD8E757
BOTTOM CUSHION . TPD8E758
INSTRUCTION BOOKS
GERMAN/SPANISH TQB8E3342AE
DUTCH/FRENCH TQB8E3342BD
SWEDISH/NORWEGIAN TQB8E3342FG
DANISH/FINNISH(SUOMI) TQB8E3342HK
