DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COILS
COIL L574 ELHKLB040B
COIL L576 ELC18B801L
COIL L579 ELHKLB061B
COIL L702 ELC18B121E
COIL L2005 EXCELDR35V
RESISTORS
S.M.CARBJSA81 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSZ7 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR353 ERJ6ENF1501 0.1W 1% 1R5K
S.M.CARBR363 ERJ6ENF1501 0.1W 1% 1R5K
S.M.CARBR372 ERJ6ENF1501 0.1W 1% 1R5K
S.M.CARBR386 ERJ6GEYJ101 0.1W 5% 100
CARBONR451 ERDS1TJ2R7 0.5W 5% 2R7
CARBONR452 ERDS1TJ2R7 0.5W 5% 2R7
S.M.CARBR473 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR474 ERJ6GEYJ103 0.1W 5% 10K
METALR509 ERX3FJ1R0 3W 5% 1
CARBONR520 ERD25TJ153 0.25W 5% 15K
METALR521 ERG2FJS123 2W 5% 12K
CARBONR522 ERD25TJ101 0.25W 5% 100
CARBONR523 ERD25TJ103 0.25W 5% 10K
CARBONR524 ERD25TJ103 0.25W 5% 10K
CARBONR525 ERD25TJ102 0.25W 5% 1K
SOLIDR526 ERC14GK184 0.25W 5% 180K
SOLIDR527 ERC14GK224 1/4W 5% 220K
CARBONR530 ERD25TJ101 0.25W 5% 100
SOLIDR531 ERC14GK334 0.25W 10% 330K
CARBONR532 ERD25TJ473 0.25W 5% 47K
METALR533 ERG3FJS821 3W 5% 820
CARBONR534 ERDS2TJ333T 2W 5% 33K
METALR535 ERG1FJS332 1W 5% 3R3K
METALR536 ERG3FJS821 3W 5% 820
SOLIDR538 ERC14GK225 1/4W 5% 2.2M
CARBON R540 ERD25TJ560 0.25W 5% 56
CARBONR555 ERD25TJ473 0.25W 5% 47K
WOUNDR556 ERF2AKR22 0.5W 5% R22
CARBONR558 ERDS1TJ333 0.5W 5% 33K
CARBON R559 ERD25TJ273 0.25W 5% 27K
CARBONR560 ERD25TJ183 0.25W 5% 18K
CARBONR581 ERDS2TJ104T 2W 5% 100K
CARBONR582 ERD25TJ124 0.25W 5% 120K
CARBONR583 ERD25TJ103 0.25W 5% 10K
METAL R586 ERQ2CJP2R2 2W 5% 2R2
METALR591 ERO25TKF9311 0,25W 1% 9K31
S.M.CARBR965 ERJ6GEYJ683 0.1W 5% 68K
S.M.CARBR967 ERJ6GEYJ683 0.1W 5% 68K
S.M.CARBR1458 ERJ6ENF6801 0.1W 1% 6K8
S.M.CARBR2481 ERJ6GEYJ473 0.1W 5% 47K
CAPACITORS
FILMC473 ECQV1H104J 50V 100nF
CERAMICC474 ECJ2VF1H103Z 50V 10nF
CERAMIC C521 ECKC3A152J 1KV 1500pF
CERAMICC522 ECKC3A272J 1KV 2.7µF
CERAMICC523 ECKC3A151J 1KV 150pF
FILMC524 ECQM6223JZW 600V 22nF
FILMC525 ECQM4223JZW 400V 22nF
CERAMICC526 ECKC3D101J 2KV 100pF
ELECT C527 ECA1HM010GB 50V 1µF
CERAMIC C528 ECKC3D471JB 2KV 470pF
ELECT C529 ECA1HM100GB 50V 10µF
CERAMICC530 ECKC3A681J 1KV 680pF
CERAMIC C531 ECKC3D102J 2KV 1nF
CERAMIC C554 ECKC3D681J 2KV 680pF
FILMC558 ECWH20472JVB 200V 4.7nF
FILMC559 ECQF4123JZH 400V 12nF
FILMC561 ECWH20512JVB 200V 5.1nF
FILMC562 ECQM4223KC 400V 220nF
FILMC577 ECWF2274JBB 200V 270nF
FILMC578 ECWF4304JBP 400V 300nF
FILMC579 ECWF4334JBB 400V 330nF
FILMC580 ECWF4474JBB 400V 470nF
FILMC583 ECQB1H223K 50V 22nF
CERAMICC1500 EEVHB1C101P 16V 100pF
TERMINALS AND LINKS
CRT SOCKET JK351 TJS1A5330
DIFFERENCES FOR MODEL TX--36PB50D
EXPLODED VIEW
A P.C.B. 19 TNPH0348BS
ANODE CABLE 20 ZTBZAD650E
BACK COVER 21 TKU8E00700
C.R.T. 22 W86LPX955X07
CABINET 23 TKY8E580
D P.C.B. 25 TNPH0349
DEGAUSS COIL 26 TLK8E05147
DF P.C.B. 27 TNPA1806
FBT 28 ZTFM77009A
FOCUS LEAD ASSEMBLY 29 TXJF0C0EFG
G P.C.B. 30 TNP8EG004AB
L P.C.B. 31 TNPA1726
MODEL LABEL 32 TQF8E3204-1
PANASONIC BADGE 33 TBMA059
MISCELLANEOUS COMPONENTS
PRESET LABELRIGHT. TBM8E2138
LID SWITCH . TEK6935
SPEAKER PANEL LEFT. TKP8E1437
SPEAKER PANEL RIGHT. TKP8E1442
BOTTOM PANEL LEFT. TKP8E1446
BOTTOM PANEL RIGHT. TKP8E1456-1
TOP CARTON . TPC8E4908
BOTTOM CARTON . TPC8E4909
CARTON HANDLE . TPD169487
BOTTOM CUSHION . TPD8E764
SUB CUSHION . TPD8E778
SERVICE PACK . TZS1EK002
DEGAUSS RESISTOR R537 ERC12GK104V
CRT EARTH SPRING SK401 TES2298
CRT EARTH SPRING SK402 TES2298
SPEAKER (WOOFER) SPK1 EAB12149C2
SPEAKER (WOOFER) SPK2 EAB12149C2
SPEAKER (TWEETER) SPK3 EASG7DH08B2
SPEAKER (TWEETER) SPK4 EASG7DH08B2
CRT EARTH SPRING TES01 TES2298
CRT EARTH SPRING TES02 TES2298
INSTRUCTION BOOKS
GERMAN TQB8E3514A
ITALIAN TQB8E3514C
FRENCH TQB8E3514D
I.C.s
VERTICAL OUTPUT IC451 LA7876N
EAROM * IC1104 X24BR200-2ID
2.5V REGULATOR IC1252 PQ30RV21B
VIDEO PROCESSOR IC1304 C1AB00001230
2.5V REGULATOR IC2402 PQ30RV21B
DIODES
DIODE D450 EU02AV1
DIODE D521 AU02AV0
39
