DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number

TRANSISTORS

TRANSISTOR Q120 2SC5343Y

TRANSISTOR Q401 2SD2578

TRANSISTOR Q402 2SD1207

TRANSISTOR Q501 2SC5343Y

TRANSISTOR Q502 2SA1980Y

TRANSISTOR Q503 2SC5343Y

TRANSISTOR Q504 2SA1980Y

TRANSISTOR Q506 2SC5343Y

TRANSISTOR Q508 2SC5343Y

TRANSISTOR Q513 2SA1980Y

TRANSISTOR Q515 H2N7000

TRANSISTOR Q601 2SC5343Y

TRANSISTOR Q602 2SA1980Y

TRANSISTOR Q807 KSA1013Y

TRANSISTOR Q809 2SC5343Y

TRANSISTOR Q810 2SC5343Y

TRANSISTOR Q812 KTC3203-Y

TRANSISTOR Q813 2SA1980Y

TRANSISTOR Q814 2SC5343Y

TRANSISTOR Q815 2SA1980Y

TRANSISTOR Q816 2SC5343Y

TRANSFORMERS

TRANSFORMER DRIVET401 TD-19A1

TRANSFORMER SMPS T801 50M4242C7-

COILS

PEAKING COIL L101 5CPZ100K02

COIL PEAKING L350 5CPZ109K04

COIL PEAKING L351 5CPZ109K04

COIL H-LINEARITY L401 58H0000041

COIL CHOKE L402 58C7070085

PEAKING COIL L505 PZ479K02

PEAKING COIL L506 PZ479K02

PEAKING COIL L507 PZ479K02

PEAKING COIL L508 PZ479K02

PEAKING COIL L509 PZ479K02

PEAKING COIL L510 PZ479K02

PEAKING COIL L512 PZ479K02

PEAKING COIL L513 PZ479K02

PEAKING COIL L514 5CPZ100K04

PEAKING COIL L515 5CPZ100K02

PEAKING COIL L516 PZ479K02

COIL PEAKING L517 5CPZ479K04

COIL PEAKING L518 5CPZ479K04

COIL PEAKING L519 5CPZ479K04

PEAKING COIL L523 PZ479K02

COIL BEAD L650 5MC0000100

COIL BEAD L801 5MC0000100

COIL CHOKE L802 58CX430599

COIL BEAD L803 5MC0000100

PEAKING COIL R713 5CPZ560K02

FILTERS

FILTER LINE LF801 5PLF24A3

FILTER SAW Z101 K3953M

FILTER SAW Z102 5PK9650M--

FILTER EMI Z601 5PEFST471Y

FILTER EMI Z602 5PEFST471Y

FILTER EMI Z603 5PEFST471Y

FILTER EMI Z604 5PEFST471Y

FILTER EMI Z605 5PEFST471Y

FILTER EMI Z606 5PEFST471Y

FILTER EMI Z607 5PEFST471Y

FILTER EMI Z608 5PEFST471Y

FILTER EMI Z609 5PEFST471Y

FILTER EMI Z610 5PEFST471Y

FILTER EMI Z611 5PEFST471Y

FILTER EMI Z612 5PEFST471Y

CRYSTALS

CRYSTAL QUARTZ X501 5XJ24R576E

RESISTORS

CARBONJ7 ERD25TJ101 0.25W 5% 100 Ω

CARBONJ25 ERD25TJ101 0.25W 5% 100 Ω

CARBONJ26 ERD25TJ101 0.25W 5% 100 Ω

CARBONJ50 ERD25TJ101 0.25W 5% 100 Ω

CARBON J76 ERD25TJ202 0.25W 5% 2K Ω

CARBONJ83 ERD25TJ101 0.25W 5% 100 Ω

CARBONJ84 ERD25TJ101 0.25W 5% 100 Ω

CARBON R103 ERD25TJ393 0.25W 5% 39K Ω

CARBONR104 ERD25TJ683 0.25W 5% 68K Ω

CARBONR105 ERD25TJ103 0.25W 5% 10K Ω

CARBONR106 ERD25TJ101 0.25W 5% 100 Ω

CARBONR107 ERD25TJ101 0.25W 5% 100 Ω

CARBONR114 ERD25TJ473 0.25W 5% 47K Ω

CARBONR115 ERD25TJ101 0.25W 5% 100 Ω

CARBONR120 ERD25TJ101 0.25W 5% 100 Ω

CARBONR131 ERD25TJ472 0.25W 5% 4K7 Ω

CARBONR310 ERD25TJ471 0.25W 5% 470 Ω

CARBONR311 ERD25TJ471 0.25W 5% 470 Ω

CARBONR331 ERDS1TJ201 0.5W 5% 200 Ω

CARBONR340 ERD25TJ473 0.25W 5% 47K Ω

METALR350 RN-AZ2201F 0.17W - 2K2 Ω

METALR351 RN-AZ2201F 0.17W - 2K2 Ω

CARBONR370 ERD25TJ159 0.25W 5% 1.5 Ω

CARBONR394 ERD25TJ272 0.25W 5% 2K7 Ω

CARBONR395 ERD25TJ394 0.25W 5% 390K Ω

CARBONR396 ERD25TJ103 0.25W 5% 10K Ω

CARBONR397 ERD25TJ823 0.25W 5% 82K Ω

METALR398 RS02Y129JS 2W - 1R2 Ω

METALR399 RS02Y120JS 2W - 12 Ω

CARBONR401 ERD25TJ272 0.25W 5% 2K7 Ω

CARBONR402 ERD25TJ220 0.25W 5% 22 Ω

CARBONR403 ERD25TJ102 0.25W 5% 1K Ω

CARBONR404 ERD25TJ109 0.25W 5% 1 Ω

CARBONR405 ERD25TJ102 0.25W 5% 1K Ω

METALR406 RS02Y471JS 2W - 470 Ω

CARBONR407 ERD25TJ182 0.25W 5% 1K8 Ω

METALR415 RN02B112JS 2W - 1K1 Ω

CARBONR420 ERDS1TJ103 0.5W 5% 10K Ω

CARBONR422 ERD25TJ102 0.25W 5% 1K Ω

CARBONR423 ERD25TJ392 0.25W 5% 3K9 Ω

METALR444 RS02Y478JS 2W - R47 Ω

METALR450 ERG2FJ473 2W 5% 47K Ω

METALR451 ERG2FJ473 2W 5% 47K Ω

CARBONR500 ERD25TJ101 0.25W 5% 100 Ω

CARBONR501 ERD25TJ332 0.25W 5% 3K3 Ω

CARBONR502 ERD25TJ332 0.25W 5% 3K3 Ω

CARBONR503 ERD25TJ102 0.25W 5% 1K Ω

CARBONR504 ERD25TJ152 0.25W 5% 1K5 Ω

CARBONR505 ERD25TJ101 0.25W 5% 100 Ω

CARBONR506 ERD25TJ103 0.25W 5% 10K Ω

CARBONR507 ERD25TJ332 0.25W 5% 3K3 Ω

CARBONR508 ERD25TJ332 0.25W 5% 3K3 Ω

CARBONR510 ERD25TJ103 0.25W 5% 10K Ω

CARBONR511 ERD25TJ103 0.25W 5% 10K Ω

CARBONR512 ERD25TJ101 0.25W 5% 100 Ω

CARBONR513 ERD25TJ101 0.25W 5% 100 Ω

CARBONR514 ERD25TJ101 0.25W 5% 100 Ω

CARBONR515 ERD25TJ101 0.25W 5% 100 Ω

CARBONR516 ERD25TJ153 0.25W 5% 15K Ω

CARBONR517 ERD25TJ101 0.25W 5% 100 Ω

CARBONR518 ERD25TJ101 0.25W 5% 100 Ω
