Panasonic TX-29PM1D - Important Safety Notice; Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Important Safety Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
MASK FRONT 1 4852089314
COVER BACK 2 4852170214
DOOR 3 4852825211
BUTTON POWER 4 4854868711
MARK BRAND 5 4855624800
SCREW CRT FIX 6 4856017354
TUNER VARACTOR 7 4859724930
PCB MAIN 8 4859810593
PCB CRT 9 4859810593-C
POWER CORD 10 4859906210
SPEAKER SYSTEM 11 48A8309000
FBT 12 50H0000277
COIL DEGAUSSING 13 58G0000149
CRT 14 A68EPD10X22
REMOTE CONTROL 15 EUR7628030
MISCELLANEOUS COMPONENTS
POWER BUTTON SPRING M481A 4856716000
DECO CTRL M501 4855061600
DECO SENSOR M551 4855553500
DOOR LOCK M791 LA701
I.C.s
IC VERTICAL I301 TDA8358J
IC AUDIO I602 TDA8946J
PREAMP I703 TSOP1238WI1
IC POWER I801 STR-W6754
PHOTO COUPLER I804 KP1010C
IC ERROR AMP I806 DP130
IC REGULATOR I820 L7805CV
IC REGULATOR I822 KIA78R08API
IC REGULATOR I823 LD1117V33
IC REGULATOR I824 L7805CV
IC VIDEO I901 TDA6107AJ
FUSES
FUSE 4A250V F801 5FSCB4022R
DIODES
DIODE D101 DBAT85
DIODE D102 BA282
DIODE D313 1N4937G
DIODE D403 DBY228
DIODE D404 DBYW76
DIODE D405 1N4937G
DIODE D407 RGP15J
DIODE D408 RGP15J
DIODE D410 1N4004S
DIODE D411 1N4004S
DIODE D414 1N4004S
DIODE D450 1N4937G
DIODE D501 DBAT85
DIODE D503 DTZX3V9B
DIODE D504 DTZX5V6B
DIODE D520 1N4148
DIODE D521 1N4148
DIODE D522 DTZX3V9B
DIODE D523 DTZX3V9B
DIODE D601 1N4148
DIODE D602 1N4148
DIODE D710 DTZX5V6B
DIODE D801 LT2A05G
DIODE D802 LT2A05G
DIODE D803 LT2A05G
DIODE D804 LT2A05G
DIODE D805 1N4937G
DIODE D806 1N4937G
DIODE D807 1N4937G
DIODE ZENER D808 DUZ6R8BM
DIODE D811 DTZX5V1B
DIODE D820 DBYW76
DIODE D824 DTZX5V1B
DIODE D825 1N4148
DIODE D830 1N4937G
DIODE D831 1N4937G
DIODE D860 RGP30J
DIODE D904 DBAV21
DIODE D905 DBAV21
DIODE D906 DBAV21
DIODE D997 LT2A05G
DIODE DA01 1N4148
DIODE DA02 DTZX5V6B
DIODE DA03 1N4148
DIODE DA04 DTZX5V6B
DIODE DA06 DTZX5V6B
DIODE DA08 DTZX5V6B
DIODE DA09 DTZX5V6B
DIODE DA10 DTZX5V6B
DIODE DA11 DTZX5V6B
DIODE DA13 DTZX5V6B
DIODE DA14 DTZX5V6B
DIODE DA15 DTZX5V6B
DIODE DA20 DTZX5V6B
DIODE DA21 DTZX5V6B
DIODE DA22 DTZX5V6B
DIODE ZENER I805 DTZX33B
10
