Panasonic TX-32LX85F - Page 40

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC8056 F1G1C104A116 16V 100nF
S.M.CAPC8057 F1G1C104A116 16V 100nF
S.M.CAPC8058 F1J1A106A043 10V 10µF
S.M.CAPC8067 F1G1E103A123 25V 10nF
S.M.CAPC8068 F1G1C104A116 16V 100nF
S.M.CAPC8069 F1G1H820A731 50V 82pF
S.M.CAPC8070 F1G1C104A116 16V 100nF
S.M.CAPC8071 F1G1C104A116 16V 100nF
S.M.CAPC8072 F1G1C104A116 16V 100nF
S.M.CAPC8073 F1G1C104A116 16V 100nF
S.M.CAPC8074 F1G1C104A116 16V 100nF
S.M.CAPC8075 F1J0G2260001 4V 22µF
S.M.CAPC8076 F1G1C104A116 16V 100nF
S.M.CAPC8077 F1G1C104A116 16V 100nF
S.M.CAPC8078 F1G1C104A116 16V 100nF
S.M.CAPC8079 F1G1C104A116 16V 100nF
S.M.CAPC8080 F1G1C104A116 16V 100nF
S.M.CAPC8090 ECJ1VB1C103K 16V 10nF
S.M.CAPC8091 ECJ1VB1C103K 16V 10nF
S.M.CAPC8092 ECJ1VB1C103K 16V 10nF
S.M.CAPC8093 ECJ1VB1C103K 16V 10nF
S.M.CAPC8094 ECJ1VB1C103K 16V 10nF
S.M.CAPC8095 ECJ1VB1C103K 16V 10nF
S.M.CAPC8555 F1G1C104A116 16V 100nF
S.M.CAPC8601 F1G1C104A116 16V 100nF
SMDC8812 F1G1A104A012 10V 100nF
ELECTC8813 F2G1C470A022 16V 47µF
S.M.CAPC8814 F1G1C1030008 16V 10nF
S.M.CAPC8815 F1J0G2260001 4V 22µF
CHIP CAPFL4206 F1H0J4740004 6.3V 470nF
TERMINALS AND LINKS
8P CONNECTOR A1 K1KA08A00506
51P CONNECTOR A5 K1KB51A00001
23P CONNECTOR A7 K1KY23AA0607
2P CONNECTOR A10 K1KA02A00787
4P CONNECTOR A12 K1KA04AA0714
6P CONNECTOR A13 K1KA06AA0104
5P CONNECTOR A14 K1KA05AA0150
15P CONNECTOR A51 K1KA15A00148
A51-G51 WIRE A51-G51 TXJA51NUA-1
8P CONNECTOR CN0100 K1KA08AA0714
15P CONNECTOR G51 K1KA15AA0194
PC TERMINAL JK3001 K1FB315A0006
SCART SOCKET JK3002B K1FY121A0004
SCART SOCKET JK3003B K1FY121A0004
YUV TERMINAL_ AUD I/OJK3100A K2HA7YYA0001
AV3 TERMINAL JK3700 K4AK30B00001
HDMI TERMINAL JK4500 K1FY119D0003
HDMI TERMINAL JK4501 K1FY119D0003
HDMI TERMINAL JK4700 K1FA119E0013
SD SLOT JK8801 K1NA09E00080
4P CONNECTOR K1 K1KA04BA0061
2P CONNECTOR P1 K1KA02A00720
23P CONNECTOR P2 K1KY23AA0606
8P CONNECTOR P5 K1KA08AA0192
8P CONNECTOR V1 K1KA08B00270
EARTH LUG ZA851 K9ZZ00000424
SWITCHES
SWITCH SW2501 K0F162B00002
RELAYS
RELAY RL801 K6B2ADA00007
DIFFERENCES FOR MODEL TX--32LX85F
EXPLODED VIEW
A P.C.B. 15 A-32LX85F
AC CORD ASSY 16 TXASX01NXA-1
BACK COVER 17 TKU0E1701
CABINET ASSY 19 TTY0E0312
L CHASSIS FRAME BRACKE 20 TUA0E2600
LCD PANEL 22 L5EDD8Q00040
MODEL LABEL 23 TBM0E1441
PEDESTAL ASSY 24 TTX0E0008
POWER BUTTON BRACKET 25 TKP0E91701
R CHASSIS FRAME BRACKE 26 TUA0E2900
TRIM PANEL 27 TKP0E35601
MISCELLANEOUS COMPONENTS
IR/LED PANEL . TKP0E91502
BOTTOM CUSHION BOTCUS TPD0E2020
CARTON CARTON TPC0E49600
TOP CUSHION TOPCUS TPD0E1047
INSTRUCTION BOOKS
GERMAN . TQB0E0664A-1
DUTCH . TQB0E0664B-1
ITALIAN . TQB0E0664C-1
FRENCH . TQB0E0664D-1
SPANISH . TQB0E0664E-1
SWEDISH . TQB0E0664F-1
NORWEGIAN . TQB0E0664G-1
FINNISH . TQB0E0664H-1
LITHUANIAN . TQB0E0664I-1
PORTUGUESE . TQB0E0664J-1
DANISH . TQB0E0664K-1
BULGARIAN . TQB0E0664M-1
ROMANIAN . TQB0E0664N-1
LATVIAN . TQB0E0664O-1
POLISH . TQB0E0664P-1
HUNGARIAN . TQB0E0664Q-1
CZECH . TQB0E0664R-1
GREEK . TQB0E0664S-1
TURKISH . TQB0E0664T-1
ENGLISH . TQB0E0664U-1
CROATIAN . TQB0E0664V-1
SLOVAKIAN . TQB0E0664W-1
CD ROM . TQB0E0664X1
ESTONIAN . TQB0E0664Z-1
I.C.s
EEPROM PL2 IC8601 X24C32LX85F
TERMINALS AND LINKS
A1-V1 WIRE A1-V1 TXJA1NXA
A5-PANEL WIRE A5-PAN K1PY51Y00015
A12-K1 WIRE A12-K1 TXJA12NGA-1
A14-SPK WIRE A14-SPK TXJA14NXA-4
CN101-A13/P5 WIRECN-A,P TXJP5NVA-1
DIFFERENCES FOR MODEL TX--32LX85L
EXPLODED VIEW
A P.C.B. 15 A-32LX85L
AC CORD ASSY 16 TXASX01NJA-1
BACK COVER 17 TKU0E1701
CABINET ASSY 19 TTY0E0312
L CHASSIS FRAME BRACKE 20 TUA0E2600
LCD PANEL 22 L5EDD8Q00040
MODEL LABEL 23 TBM0E1464-1
PEDESTAL ASSY 24 TTX0E0008
POWER BUTTON BRACKET 25 TKP0E91701
R CHASSIS FRAME BRACKE 26 TUA0E2900
TRIM PANEL 27 TKP0E35601
MISCELLANEOUS COMPONENTS
IR/LED PANEL . TKP0E91502
BOTTOM CUSHION BOTCUS TPD0E2020
40
