Panasonic TX-32LX85F - Page 41

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
CARTON CARTON TPC0E49600
TOP CUSHION TOPCUS TPD0E1047
INSTRUCTION BOOKS
ENGLISH . TQB0E0681-1
I.C.s
EEPROM PL2 IC8601 X24C32LX85L
TERMINALS AND LINKS
A1-V1 WIRE A1-V1 TXJA1NXA
A5-PANEL WIRE A5-PAN K1PY51Y00015
A12-K1 WIRE A12-K1 TXJA12NGA-1
A14-SPK WIRE A14-SPK TXJA14NXA-4
CN101-A13/P5 WIRECN-A.P TXJP5NVA-1
DIFFERENCES FOR MODEL TX--32LX85P
EXPLODED VIEW
A P.C.B. 15 A-32LX85P
AC CORD ASSY 16 TXASX01NXA-1
BACK COVER 17 TKU0E1701
CABINET ASSY 19 TTY0E0312
L CHASSIS FRAME BRACKE 20 TUA0E2600
LCD PANEL 22 L5EDD8Q00040
MODEL LABEL 23 TBM0E1442
PEDESTAL ASSY 24 TTX0E0008
POWER BUTTON BRACKET 25 TKP0E91701
R CHASSIS FRAME BRACKE 26 TUA0E2900
TRIM PANEL 27 TKP0E35601
MISCELLANEOUS COMPONENTS
IR/LED PANEL . TKP0E91502
BOTTOM CUSHION BOTCUS TPD0E2020
CARTON CARTON TPC0E49600
TOP CUSHION TOPCUS TPD0E1047
INSTRUCTION BOOKS
GERMAN . TQB0E0663A-1
DUTCH . TQB0E0663B-1
ITALIAN . TQB0E0663C-1
FRENCH . TQB0E0663D-1
SPANISH . TQB0E0663E-1
SWEDISH . TQB0E0663F-1
NORWEGIAN . TQB0E0663G-1
FINNISH . TQB0E0663H-1
LITHUANIAN . TQB0E0663I-1
PORTUGUESE . TQB0E0663J-1
DANISH . TQB0E0663K-1
BULGARIAN . TQB0E0663M-1
ROMANIAN . TQB0E0663N-1
LATVIAN . TQB0E0663O-1
POLISH . TQB0E0663P-1
HUNGARIAN . TQB0E0663Q-1
CZECH . TQB0E0663R-1
GREEK . TQB0E0663S-1
TURKISH . TQB0E0663T-1
ENGLISH . TQB0E0663U-1
CROATIAN . TQB0E0663V-1
SLOVAKIAN . TQB0E0663W-1
CD ROM . TQB0E0663X1
ESTONIAN . TQB0E0663Z-1
I.C.s
EEPROM PL2 IC8601 X24C32LX85P
TERMINALS AND LINKS
A1-V1 WIRE A1-V1 TXJA1NXA
A5-PANEL WIRE A5-PAN K1PY51Y00015
A12-K1 WIRE A12-K1 TXJA12NGA-1
A14-SPK WIRE A14-SPK TXJA14NXA-4
CN101-A13/P5 WIRECN-A,P TXJP5NVA-1
DIFFERENCES FOR MODEL TX--37LX85F
EXPLODED VIEW
A P.C.B. 15 A-37LX85F
AC CORD ASSY 16 TXASX01NXA-1
BACK COVER 17 TKU0E1801
BOTTOM LCD BRACKET 18 TUA0E3600
CABINET ASSY 19 TTY0E0316
L CHASSIS FRAME BRACKE 20 TUA0E3200
LCD BRACKET 21 TKZ0E9160
LCD PANEL 22 L5EDD9Q00004
MODEL LABEL 23 TBM0E1468
PEDESTAL ASSY 24 TTX0E0007
POWER BUTTON BRACKET 25 TKP0E91801
R CHASSIS FRAME BRACKE 26 TUA0E3400
TRIM PANEL 27 TKP0E35401
MISCELLANEOUS COMPONENTS
IR/LED PANEL . TKP0E91602
BOTTOM CUSHION BOTCUS TPD0E2021
CARTON CARTON TPC0E49700
TOP CUSHION TOPCUS TPD0E1048
INSTRUCTION BOOKS
GERMAN . TQB0E0664A-1
DUTCH . TQB0E0664B-1
ITALIAN . TQB0E0664C-1
FRENCH . TQB0E0664D-1
SPANISH . TQB0E0664E-1
SWEDISH . TQB0E0664F-1
NORWEGIAN . TQB0E0664G-1
FINNISH . TQB0E0664H-1
LITHUANIAN . TQB0E0664I-1
PORTUGUESE . TQB0E0664J-1
DANISH . TQB0E0664K-1
BULGARIAN . TQB0E0664M-1
ROMANIAN . TQB0E0664N-1
LATVIAN . TQB0E0664O-1
POLISH . TQB0E0664P-1
HUNGARIAN . TQB0E0664Q-1
CZECH . TQB0E0664R-1
GREEK . TQB0E0664S-1
TURKISH . TQB0E0664T-1
ENGLISH . TQB0E0664U-1
CROATIAN . TQB0E0664V-1
SLOVAKIAN . TQB0E0664W-1
CD ROM . TQB0E0664X1
ESTONIAN . TQB0E0664Z-1
I.C.s
EEPROM PL2 IC8601 X24C37LX85F
TERMINALS AND LINKS
A1-V1 WIRE A1-V1 TXJA1NUA-1
A5-PANEL WIRE A5-PAN K1PY51Y00016
A12-K1 WIRE A12-K1 TXJA12NUA
A14-SPK WIRE A14-SPK TXJA14NUA-3
CN101-A13/P5 WIRECN-A,P TXJP5NUA-1
DIFFERENCES FOR MODEL TX--37LX85L
EXPLODED VIEW
A P.C.B. 15 A-37LX85L
AC CORD ASSY 16 TXASX01NJA-1
BACK COVER 17 TKU0E1801
BOTTOM LCD BRACKET 18 TUA0E3600
CABINET ASSY 19 TTY0E0316
L CHASSIS FRAME BRACKE 20 TUA0E3200
LCD BRACKET 21 TKZ0E9160
41
