English
7
Accessories
Standard accessories
Remote Control
(p. 14)
N2QAYB001109
Pedestal
(p. 7)
32-inch model
40-inch model
49-inch model
Mains lead
(p. 11)
32-inch model
49-inch model
40-inch model
Batteries (2)
R6
(p. 15)
Operating Instructions
Pan European Guarantee Card
Accessories may not be placed all together. Take care
not to throw them away unintentionally.
Assembling / Removing the pedestal
32-inch model
Assembly screw (4)
Assembly screw (4)
M4 × 15
Bracket
Base (2)
Preparations
Take out the pedestal and the TV from the packing case
and put the TV onto a work table with the screen panel
down on the clean and soft cloth (blanket, etc.).
Use a flat and firm table bigger than the TV.
Do not hold the screen panel part.
Make sure not to scratch or break the TV.
To Next Page
