Panasonic TX-40JX800E - Technical Specifications; Model Numbers and Dimensions; Weight and Power Specifications; Audio, Panel, and Connectivity Specs

English
22
Specifications
 TV
Model No.
40-inch model
:
TX-40JX800E, TX-40JX800EZ,
TX-40JX810E, TX-40JX820E
50-inch model
:
TX-50JX800E, TX-50JX800EZ,
TX-50JX810E, TX-50JX820E
58-inch model
:
TX-58JX800E, TX-58JX800EZ,
TX-58JX810E, TX-58JX820E
65-inch model
:
TX-65JX800E, TX-65JX800EZ,
TX-65JX810E, TX-65JX820E
Dimensions (W × H × D)
40-inch model
904 mm × 548 mm × 174 mm (With Pedestal)
904 mm × 524 mm × 65 mm (TV only)
50-inch model
1 123 mm × 682 mm × 247 mm (With Pedestal)
1 123 mm × 657 mm × 62 mm (TV only)
58-inch model
1 300 mm × 787 mm × 247 mm (With Pedestal)
1 300 mm × 762 mm × 65 mm (TV only)
65-inch model
1 459 mm × 872 mm × 271 mm (With Pedestal)
1 459 mm × 847 mm × 62 mm (TV only)
Mass
40-inch model
7.0 kg Net (With Pedestal)
6.7 kg Net (TV only)
50-inch model
10.4 kg Net (With Pedestal)
9.9 kg Net (TV only)
58-inch model
14.8 kg Net (With Pedestal)
14.3 kg Net (TV only)
65-inch model
20.9 kg Net (With Pedestal)
20.3 kg Net (TV only)
Power source
AC 220-240 V, 50 / 60 Hz
Panel
LED backlight Liquid Crystal Display
Sound
Speaker output
20 W (10 W × 2)
Headphones
3.5 mm stereo mini jack × 1
Connection terminals
AV input
VIDEO
1.0 V[p-p] (75 :)
AUDIO L - R
0.5 V[rms]
HDMI 1 / 2 / 3 input
TYPE A Connectors
HDMI 1 / 3:
4K, Content Type, Deep Colour, x.v.Colour™
HDMI 2:
4K, Content Type, ARC (Audio Return Channel),
Deep Colour, x.v.Colour™
Card slot
Common Interface slot (complies with CI Plus) × 1
ETHERNET
RJ45, IEEE802.3 10BASE-T / 100BASE-TX
USB 1 / 2
USB 1 / 2: DC
5 V, Max. 500 mA [Hi-Speed
USB (USB 2.0)]
DIGITAL AUDIO OUT
PCM / Dolby Audio, Fibre optic
