Panasonic TX-50CX670E - Measurements and Adjustments; Voltage Chart of P-Board; Voltage Chart of A-Board

38
9 Measurements and Adjustments
9.1. Voltage chart of P-board
9.2. Voltage chart of A-board
Power Supply Name Test point Spec
28V TP7407, TP7408, TP7409 27.4 ± 2V
16V TP7410, TP7411, TP7412 15.7 ± 0.6V
5V TP7405, TP7420 5.1 ± 0.2V
PFC TP7201, TP7202 390V ± 15V *HOT
Power Supply Name Test point Spec
PNL12V TP5013 12V ± 1.2V
USB5V TP5010 5.17V ± 0.25V
USB1 TP8629 5.0V ± 0.25V
USB2 TP8655 5.0V ± 0.25V
USB3 TP8631 5.0V ± 0.25V
USB-WiFi TP8648 5.14V ± 0.20V
SUB3.3V TP5001 3.39V ± 0.15V
HDMISW3.3V TP4514 3.35V ± 0.17V
SUB_AI_3.3V TP2206 3.3V ± 0.17V
STB_1.5V TP8101 1.52V ± 0.07V
SUB1.0V TP8100 1.02V ± 0.05V
AVDD1.0V TP8102 1.06V ± 0.05V
NT2.5V TP9170 2.52V ± 0.12V
NT1.5V TP9160 1.52V ± 0.07V
NT1.1V TP9150 1.13V ± 0.06V
HDMI1.1V TP4503 1.13V ± 0.06V
WOL3.3V TP8646 3.3V ± 0.17V
PHY3.3V TP8646 3.3V ± 0.17V
EU_TU_1.8V TP5704 1.84V ± 0.1V
SUB9V TP5004 9V ± 0.4V
T2_1.1V TP5705 1.15V ± 0.11V
SUB_CI_5V TP8400 5.0V ± 0.5V
