12
English
≥ Be careful not to nip the cables between the TV and
the cable cover.
≥ Do not apply load to the cable cover.
≥
≥
≥
≥≥ To remove from the TV:
≥ Do not place any objects within the full rotation range.
Be sure to remove the pedestal in the following
procedures when you use the wall-hanging bracket or
repack the TV.
1 Remove the cable cover C.
2 Remove the assembly screws B from the pedestal.
3 Pull out the pedestal from the TV.
Attaching the cable cover
To Next Page
