8
3D Eyewear
Note
• 3D Eyewear and Touch Pad Controller use Bluetooth wireless technology.
• Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
• For the information of the open source software, refer to [eHELP] (Support > Licence).
• This equipment complies with the EMC standards listed below. (E/W)
EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024 (E/W)
PAL D, K, SECAM D, K VHF R1 - R2
VHF R6 - R12
VHF R3 - R5
UHF E21 - E69
PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR)
M.NTSC Playback from M.NTSC Video recorders (VCR)
NTSC (AV input only) Playback from NTSC Video recorders (VCR)
Satellite dish input Female F-type 75 2
Aerial input VHF / UHF
Operating Conditions
Temperature: 0 °C - 35 °C
Humidity: 20 % - 80 % RH (non-condensing)
Built-in Camera
Focus: Fixed focus
Resolution: 1 920 1 080
Built-in wireless LAN
Standard compliance and Frequency range*
2
IEEE802.11a/n (E/W) 5.180 GHz - 5.320 GHz, 5.500 GHz - 5.580 GHz, 5.660 GHz - 5.700 GHz
IEEE802.11a/n (R) 5.15 GHz - 5.35 GHz, 5.47 GHz - 5.85 GHz
IEEE802.11b/g/n (E/W) 2.412 GHz - 2.472 GHz
IEEE802.11b/g/n (R) 2.400 GHz - 2.4835 GHz
Security WPA2-PSK (TKIP/AES), WPA-PSK (TKIP/AES), WEP (64 bit/128 bit)
Bluetooth wireless technology*
3
Standard Compliance Bluetooth 3.0
Frequency Range 2.402 GHz - 2.480 GHz
*
1
: With Camera pop-up: +24 mm height
*
2
: The frequency and channel differ depending on the country.
*
3
: Not all the Bluetooth compatible devices are available with this TV. Up to 5 devices can be used simultaneously
(except the 3D eyewear and VIERA Touch Pad Controller).
Dimensions (W H D) 164.7 mm 41.0 mm 170.7 mm
Mass Approx. 34 g
Usage temperature range 0 °C - 40 °C
Battery Coin-shaped lithium battery CR2025
Operation time Approx. 75 hours in continuous use of the battery made by Panasonic
Materials
Main body Resin
Lens section Liquid crystal glass
