Panasonic TX-65DX900E - Page 8

English
8
Assembling / Removing the pedestal
When using the pedestal, this TV is slightly inclined
because of the slant design adopted.
Assembly screw (4)
M4 × 12
Assembly screw (4)
M4 × 12
Bracket (2)
Base
 Assembling the pedestal
1
D
C
D
C
A
A
Insert the pedestal at a slight angle into the TV as
shown.
(View from the side)
2
3
B
