Panasonic TX-L32C4E - Page 29

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
RC RECEIVER RM2800 PNJ4815M01TV
FUSES
FUSE HOLDER F7101-2 K3GE1ZZ00001
FUSE HOLDER F7101-1 K3GE1ZZ00001
FUSE F7101 K5D502BNA005
FUSE PA4150 K5H1622A0031
FUSE PA4151 ERBSE1R50U
FUSE PA4152 ERBSE1R50U
FUSE PA7551 K5H502YA0063
DIODES
DIODE D0917 DZ2J062M0L
DIODE D1951 B0JCCE000008
DIODE D1952 DA2J10100L
DIODE D1953 DA2J10100L
DIODE D1954 DA2J10100L
DIODE D1955 B0JCCE000008
VARISTOR D2005 EZJZ0V120JA
VARISTOR D2007 EZJZ0V120JA
LED D2800 B3AGB0000060
DIODE D3130 B0ACCJ000048
DIODE D4001 DA2J10100L
DIODE D4150 B0JCDE000006
DIODE D4151 B0JDCE000017
DIODE D4152 B0JCDE000006
DIODE D4153 B0JCDE000006
DIODE D4154 B0JCDE000006
ZENER DIODE D4155 B0BC03200003
DIODE D4156 DA2J10100L
DIODE D4157 DA2J10100L
DIODE D4159 B0JCDE000006
DIODE D4160 B0JCDE000006
DIODE D4161 B0JCDE000006
DIODE D4162 B0JCDE000006
DIODE D4163 DZ2J200M0L
ZENER DIODE D4165 B0BC01000035
DIODE D4166 DA2J10100L
DIODE D4167 DA2J10100L
DIODE D4168 DA2J10100L
DIODE D4169 B0BC4R700020
ZENER DIODE D4170 DZ2J047M0L
DIODE D4171 DA2J10100L
DIODE D4172 B0JCPE000004
DIODE D4173 B0BC01700030
ZENER DIODE D4174 B0BC022A0007
DIODE D4175 DA2J10100L
DIODE D4500 B0JCCE000008
DIODE D4604 B0JCCD000020
DIODE D5172 B0BC01700015
DIODE D5173 DA2J10100L
DIODE D5174 B0BC010A0007
DIODE D5175 DA2J10100L
ZENER DIODE D5180 DZ2J033M0L
DIODE D5480 B0JCCE000008
DIODE D7101 D4EAY6210003
DIODE D7102 B0FBAT000021
DIODE D7103 D4EAY6210003
DIODE D7203 B0ECKM000038
DIODE D7204 B0BC015A0336
DIODE D7205 B0EAMR000020
ZENER DIODE D7207 DZ2J068M0L
DIODE D7208 DA2J10100L
DIODE D7209 DA2J10100L
DIODE D7302 B0HAGQ000001
DIODE D7303 B0HAGQ000001
ZENER DIODE D7304 DZ2J068M0L
DIODE D7309 B0ECKM000038
DIODE D7310 B0BC015A0336
DIODE D7314 B0BC015A0336
DIODE D7315 B0BB140A0011
DIODE D7317 B0BC027A0336
DIODE D7318 B0BC015A0336
DIODE D7319 B0ECKM000038
DIODE D7503 B0HESM000002
DIODE D7504 DZ2J220M0L
DIODE D7505 B0HAMM000108
DIODE D7507 DA2J10100L
DIODE D7801 B0ADCK000001
DIODE D7806 DA6X103Q0R
DIODE D7807 DA6X103Q0R
DIODE D7808 DA6X103Q0R
DIODE D7809 DA6X103Q0R
DIODE D7810 B0ADCK000001
DIODE D7811 B0JCKG000002
DIODE D7812 B0JCKG000002
DIODE D7813 B0BC015A0336
ZENER DIODE D7814 DZ2J150M0L
ZENER DIODE D8703 B0BC6R600005
ZENER DIODE D8705 B0BC6R600005
DIODE D8716 DA2J10100L
DIODE D8720 B0JCMD000066
TRANSISTORS
TRANSISTOR Q0900 B1ADCF000194
TRANSISTOR Q1951 B1ADCF000194
TRANSISTOR Q2001 DSC2001S0L
TRANSISTOR Q2002 B1ADGJ000008
TRANSISTOR Q2800 DSC200100L
TRANSISTOR Q2801 DSC200100L
TRANSISTOR Q2802 DSC200100L
TRANSISTOR Q3102 B1ABCF000231
TRANSISTOR Q3103 B1ABCF000231
TRANSISTOR Q4150 DSC500100L
TRANSISTOR Q4151 DSA500100L
TRANSISTOR Q4152 DSA500100L
TRANSISTOR Q4153 B1ABCF000231
TRANSISTOR Q4154 B1CFQD000001
TRANSISTOR Q4600 B1ABCF000231
TRANSISTOR Q4604 B1ABCF000231
TRANSISTOR Q4750 B1HFCFA00026
TRANSISTOR Q4751 DSA200100L
TRANSISTOR Q4971 B1AAFB000004
TRANSISTOR Q4972 B1AAFB000004
TRANSISTOR Q4973 DSA2001S0L
TRANSISTOR Q4974 DSC2001S0L
TRANSISTOR Q7201 B1CERR000057
TRANSISTOR Q7202 B1ADCE000027
TRANSISTOR Q7203 B1ABBE000003
TRANSISTOR Q7301 B1ADCE000027
TRANSISTOR Q7302 B1ADCE000027
TRANSISTOR Q7303 B1ABBE000003
TRANSISTOR Q7306 B1DFDD000019
TRANSISTOR Q7501 B1ABBE000003
TRANSISTOR Q7502 B1ABBE000003
TRANSISTOR Q7503 B1CHRE000008
TRANSISTOR Q7504 B1CHRE000008
TRANSISTOR Q7505 B1ABBE000003
TRANSISTOR Q7801 B1ADCE000027
TRANSISTOR Q7802 B1ADCE000027
TRANSISTOR Q7803 B1CFRR000016
TRANSISTOR Q7804 B1CFRR000016
TRANSISTOR Q8100 B1MBEDA00027
TRANSISTOR Q8102 B1MBEDA00027
TRANSFORMERS
TRANSFORMATOR T7201 G4DYA0000339
TRANSFORMATOR T7302 G4DYA0000338
29
