DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number

TRANSFORMATOR T7801 G4DYA0000335

TRANSFORMER T7802 G4FYA0000020

TRANSFORMER T7803 G4FYA0000020

TRANSFORMER T7804 G4EYA0000037

COILS

COIL L2001 J0JYC0000065

COIL L2750 J0JYC0000065

COIL L2752 J0JYC0000065

COIL L2754 J0JYC0000065

COIL L3002 G1C100MA0072

CHIP INDUCTOR L3102 J0JYC0000331

CHIP INDUCTOR L3103 J0JYC0000331

COIL L3108 J0JCC0000287

CHIP INDUCTOR L3111 J0JYC0000331

CHIP INDUCTOR L3112 J0JYC0000331

CHIP INDUCTOR L3113 J0JYC0000331

CHIP INDUCTOR L3116 J0JYC0000331

CHIP INDUCTOR L3117 J0JYC0000331

CHIP INDUCTOR L3118 J0JYC0000331

COIL L3121 J0JCC0000287

COIL L4150 J0JHC0000046

COIL L4151 G1C100MA0426

COIL L4152 J0JHC0000077

COIL L4153 G1C220MA0234

COIL L4200 J0JHC0000046

CHIP INDUCTOR L4700 J0JYC0000068

CHIP INDUCTOR L4701 J0JYC0000068

CHIP INDUCTOR L4702 J0JYC0000068

CHIP INDUCTOR L4703 J0JYC0000068

COIL L4800 G1CR39J00009

COIL L4801 G1CR39J00009

COIL L4802 J0JGC0000020

COIL L4803 J0JGC0000020

COIL L4804 J0JGC0000020

CHIP INDUCTOR L4808 J0JCC0000278

COIL L4900 G1C150MA0426

COIL L4901 G1C150MA0426

COIL L4902 G1C150MA0426

COIL L4903 G1C150MA0426

COIL L4904 J0JHC0000078

COIL L4905 J0JHC0000078

COIL L4906 J0JHC0000078

COIL L4907 J0JHC0000078

FILTER L7101 J0JKB0000034

FILTER L7102 J0JKB0000034

FILTER L7104 J0JKB0000034

FILTER L7105 J0JKB0000034

FILTER L7201 J0JKB0000034

FILTER L7301 J0JKB0000034

FILTER L7302 J0JKB0000034

COIL L7303 J0JKA0000038

COIL L7803 J0JKA0000038

FILTER L7804 J0JKB0000034

FILTER L7808 J0JKB0000034

FILTER L7809 J0JKB0000034

COIL L8003 J0JCC0000287

OIL B

LM18PG121SN1DL8005 J0JHC0000045

COIL BLM18PG121SN1DL8006 J0JHC0000045

COIL BLM18PG121SN1DL8007 J0JHC0000045

COIL L8009 J0JKC0000021

COIL L8015 J0JCC0000287

COIL L8016 J0JCC0000287

COIL L8100 G1C4R7MA0416

COIL L8102 G1C3R3MA0425

FILTER L8641 J0JBC0000115

COIL L8700 G1C6R8MA0416

COIL L8701 G1C100MA0416

FILTERS

FILTER FL4000 EXC28CE201U

FILTER FL4001 EXC28CE201U

FILTER FL4002 EXC28CE201U

FILTER FL4006 EXC28CE201U

LINE FILTER LF7102 G0B103H00010

LINE FILTER LF7103 G0B103H00010

CRYSTALS

CRYSTAL X8300 H0J245500113

RESISTORS

THERMISTCF7101 D4CAY3R9A004 - - 3R9 Ω

SMDJA1 D0GDR00J0004 .125W 5% 0 Ω

SMDJA2 D0GDR00J0004 .125W 5% 0 Ω

SMDJA3 D0GDR00J0004 .125W 5% 0 Ω

SMDJA4 D0GDR00J0004 .125W 5% 0 Ω

SMDJA5 D0GDR00J0004 .125W 5% 0 Ω

SMDJA6 D0GDR00J0004 .125W 5% 0 Ω

SMDJA7 D0GDR00J0004 .125W 5% 0 Ω

SMDJA8 D0GDR00J0004 .125W 5% 0 Ω

SMDJA9 D0GDR00J0004 .125W 5% 0 Ω

SMDJA10 D0GDR00J0004 .125W 5% 0 Ω

SMDJA11 D0GDR00J0004 .125W 5% 0 Ω

SMDJA12 D0GDR00J0004 .125W 5% 0 Ω

SMDJA13 D0GDR00J0004 .125W 5% 0 Ω

SMDJA14 D0GDR00J0004 .125W 5% 0 Ω

SMDJS0003 D0GAR00J0005 .063W 5% 0 Ω

SMDJS0021 D0GAR00J0005 .063W 5% 0 Ω

SMDR0800 D0GA472JA023 .063W 5% 4K7 Ω

SMDR0900 D0GA272JA023 .063W 5% 2K7 Ω

SMDR0901 D0GA272JA023 .063W 5% 2K7 Ω

SMDR0902 D0GA272JA023 .063W 5% 2K7 Ω

SMDR0904 D0GA272JA023 .063W 5% 2K7 Ω

SMDR0905 D0GA272JA023 .063W 5% 2K7 Ω

SMDR0906 D0GA272JA023 .063W 5% 2K7 Ω

SMDR0907 D0GA272JA023 .063W 5% 2K7 Ω

SMDR0910 EXB28V472JX 28V 5% 4K7 Ω

SMDR0911 D0GA473JA015 .063W 5% 47K Ω

SMDR0918 D0GA220JA023 .063W 5% 22 Ω

SMDR0919 D0GA220JA023 .063W 5% 22 Ω

SMDR0920 D0GA220JA023 .063W 5% 22 Ω

SMDR0921 D0GA220JA023 .063W 5% 22 Ω

SMDR0922 D0GA220JA023 .063W 5% 22 Ω

SMDR0923 D0GA220JA023 .063W 5% 22 Ω

SMDR0924 D0GA220JA023 .063W 5% 22 Ω

DR0925 D0

GA220JA023 .063W 5% 22 Ω

SMDR0930 D0GA220JA023 .063W 5% 22 Ω

SMDR0931 D0GA220JA023 .063W 5% 22 Ω

SMDR0932 D0GA220JA023 .063W 5% 22 Ω

SMDR0933 D0GA220JA023 .063W 5% 22 Ω

SMDR0934 D0GA680JA023 .063W 5% 68 Ω

SMDR0935 D0GA680JA023 .063W 5% 68 Ω

SMDR0936 D0GA680JA023 .063W 5% 68 Ω

SMDR0937 D0GA680JA023 .063W 5% 68 Ω

SMDR0938 D0GA680JA023 .063W 5% 68 Ω

SMDR0939 D0GA680JA023 .063W 5% 68 Ω

SMDR0940 D0GA680JA023 .063W 5% 68 Ω

SMDR0941 D0GA680JA023 .063W 5% 68 Ω

SMDR0942 D0GA680JA023 .063W 5% 68 Ω

SMDR0943 D0GA680JA023 .063W 5% 68 Ω

SMDR0944 D0GA101JA015 .063W 5% 100 Ω

SMDR0945 D0GA102JA023 .063W 5% 1K Ω

SMDR0947 D0GA680JA023 .063W 5% 68 Ω

SMDR0948 D0GA680JA023 .063W 5% 68 Ω

SMDR0949 D0GA680JA023 .063W 5% 68 Ω

SMDR0951 D0GA473JA015 .063W 5% 47K Ω

SMDR0952 D0GA102JA023 .063W 5% 1K Ω

SMDR0962 D0GA680JA023 .063W 5% 68 Ω

Panasonic TX-L32C4E - Page 30
