Panasonic TX-L32E30B - Setting Inspection and Voltage Checks; Voltage Confirmation Table

Setting Inspection
Voltage Confirmation
A board
Description Test point Voltage
SUB1.2V TP8100 1.24V - 1.31V
SUB 1.5 V TP8101 1.47V - 1.55V
SUB3.3V TP5400 3.17V – 3.43V
SUB5V TP5420 4.94V – 5.31V
USB5V TP5440 4.94V - 5.31V
PNL12V TP4056 11.5V – 12.5V
P board
Description Test point Voltage* Voltage**
24V (PANEL) TP7514 < 1V 24V ± 1.2V
16V TP7503 < 1V 16.1V ± 0.7V
TUNER5V8 TP7502 5,7V ± 0,3V 5.7V ± 0.3V
PFC TP7203 < 340V 400V ± 15V
* Connect AC 230V to P1 connector
** Connect DC 2.5V to TV_SUB_ON P2 connector – pin 8 /TP7505/ from voltage divider.
